Professional-grade Blu-ray player BD-MP1
A compact, full-featured multi-format professional Blu-ray player offering DVD/CD, SD card and USB flash memory playback.
The TASCAM BD-MP1 is a professional-grade Blu-ray player that expands the legacy of TASCAM's popular BD-01U Blu-ray player. The BD-MP1 is the perfect choice for a wide range of commercial installations, including public, educational and commercial facilities, theaters, amusement and entertainment businesses, to name a few.
DVD/CD, SD Card and USB Flash Memory Options
The versatile BD-MP1 can automatically play back content in a wide range of file formats via any of the three front-panel media input slots, including Blu-ray/DVD/CD tray, USB Flash Memory, or SD card.
Supports a Wide Range of Disc Formats
The BD-MP1 eliminates the need for discrete audio/video playback devices in an installation, offering single-source playback for a wide range of media and file formats, including Blue-ray (BD-ROM, BD-R, BD-RE), DVD (DVD-ROM, DVD-R, DVD-RW), and CD (CD-DA, CD-R).
Versatile File Format Playback Support
The BD-MP1 is the ideal single-source playback solution for commercial installations, supporting an extensive range of file formats, including Video (MPEG1, MPEG2, MPEG4 AVC, VC-1, AVCHD, WMV), Image (JPEG, GIF, PNG) and Audio (LPCM, MP3, AAC, WMA).
Power-on Play and Repeat Mode
The unique Power-on Play feature allows the BD-MP1 to start playing desired content immediately on power up, without having to engage the Play feature first. With Repeat Mode set to "on," content will automatically start, loop and play continuously until power is turned off.
Panel Lock for Secure Operation
Panel lock, IR and tray lock functions prevent accidental or user-error operation or alteration of pre-set controls in commercial installations, helping ensure consistent and reliable performance in any installation.
Hide Menu Function for Elegant Power Up Display Sequence
The monitor display can be set to show a black screen during start up rather than the manufacturer's standard factory setup and source select menus, creating an elegant and non-distracting visual start-up environment each time the system is turned on.
Dual USB Memory Ports
Two USB Memory Ports, one front panel and one back panel, allow fixed or interchangeable access to USB memory data for playback versatility.
HDMI Output for Connecting Displays
A standard rear panel HDMI Output connection provides easy, reliable plug-and-play connection to any HDMI-compatible monitor display or television.
Balanced and Unbalanced Outputs
Highlighting its appeal to commercial installation environments, the BD-MP1 offers professional-grade XLR balanced stereo analog outputs as well as RCA unbalanced stereo outputs for versatility in audio routing, connection and setup.
Coaxial and Digital Audio Output Connection
The BD-MP1 provides support for professional-grade digital audio output formats including Dolby, DTS, and others via back panel Coaxial and Digital Audio output connections. Playback of 2 channel linear PCM is also supported.
7.1 Surround Sound System
Immersive and full, rich audio playback for any commercial installation is provided via 7.1 Surround Sound System audio outputs - front & left right (FL/FR), Center (C), side left & right (SL/SR), surround back left & right (SBL/SBR) and subwoofer (SW).
IP and RS-232C Ports for External Remote Control
Seamless, reliable two-way device status feedback and control is offered for professional installations via back panel RS-232C and Ethernet connections, enabling the BD-MP1 to be integrated into more sophisticated AV setups.
Fully Accessible Front Panel Control
Control and operation of the BD-MP1's Stop, Play, Pause and Fast Forward functions as well as navigation of the MENU setup without the IR remote controller is made possible by easily accessible front panel control buttons which can be locked/unlocked as desired.
Compact 1U Rack Size
Housed in an elegant black case, the compact 1U BD-MP1 is constructed out of durable metal, facilitating standard, seamless integration in any commercial rack or application.
- Supports playback of various formats of Blu-ray, DVD, and CD discs
- Supports playback of various video, still image, and audio formats from SD cards (SD/SDHC) and USB memory
- Power on play function
- Seamless repeat function: by chapter, title, or A-B repetition
- Resume function
- Lock functions: panel, IR, and tray lock
- Hide MENU function to display only the main contents on the screen
- External remote control via LAN or RS-232C
- HDMI output port equipped
- XLR balanced output terminals equipped
- Coaxial digital audio output terminal equipped
- RCA 7.1ch audio output terminal equipped
- Audio output level volume adjust function (0dB to -40dB)
- SPDIF/Dolby/DTS digital outputs (coaxial)
- USB memory ports on front and back panel
- IR remote control included (RC-BDMP1)
- Rugged metal casing
- 1U rackmount size
- Blu-ray
- BD25, BD50, BD-ROM, BD-R, BD-RE
- DVD
- DVD-ROM, DVD-R, DVD-RW, DVD+R, DVD+RW
- CD
- CD-DA, CD-R, CD-RW
- Blu-ray
- BDMV, BDAV
- DVD
- DVD-Video, DVD-VR, AVCHD
- Video
- ASF, MPG, AVI, 3GP, DAT, MKV, MOV, M2TS, OGM, TP, TS, MP4, WMV
- Audio
- WAV, MP3, WMA, AAC, FLAC, APE
- Picture
- JPEG, GIF, PNG
- BD/DVD/USB/SD
- Sampling frequency: 44.1k/48k/64k/88.2k/96k/176.4k/192k Hz
Bit length: 16/24 bit
- CD
- Sampling frequency: 44.1k/48k Hz
Bit length: 16/24bit
- MP3/WMA
- Sampling frequency: 32k/44.1k/48k Hz
Bit length
MP3: 112k to 320k bps
WMA: 48k to 192k bps
- Connector
- HDMI 19pin Type A
- Resolution
- 480i/576i, 480p/576p, 720p, 1080i, 1080p
- Aspect ratio
- 16:9 Full, 16:9 Normal, 4:3 Pan & Scan, 4:3 Letterbox
- Video format
- NTSC, PAL, Multi
- HDMI signal system
- RGB PC level, RGB Video level, YCbCr(4:4:4), YCbCr(4:2:2)
- Coaxial
- Connector: RCA pin jack
Format: IEC60958-3(S/P DIF)
Output impedance: 75 Ohm
- Balanced
- Connector: XLR-3-32(1 : GND, 2 : HOT, 3 : COLD) x 2 (Stereo)
Output impedance: 200 Ohm
Normal output level: +4dBu (1.23 Vrms)
Maximum output level: +20dBu (7.75Vrms)
- Unbalanced
- Connector: RCA pin jack x 1 pair
Output impedance: 200 Ohm
Normal output level: -10dBV (0.316 Vrms)
Maximum output level: +6dBV (2.0Vrms)
- 7.1ch Audio outputs
- Connector: RCA pin jack x 8 (FL/FR/SL/SR/SBL/SBR/C/SW)
Connector color:
FL, SL, SBL : White
FR, SR, SBR : Red
C, SW : Black
Output impedance: 200 Ohm
Normal output level: -10dBV (0.316 Vrms)
Maximum output level: +6dBV (2.0Vrms)
- Connector
- D-sub 9pin x 1
- Format
- RS-232C compliant
- Connector
- RJ-45
- Protocol
- 10BASE-T/100BASE-TX
- Connector
- Front: USB A-type x 1
Rear: USB A-type x 1
- Protocol
- USB2.0 compliant
- Rated supply voltage
- DC 5V, 1A
- Mass storage class
- 2TB (Max)
- File format
- FAT16/FAT32/NTFS
- Media
- SD (512MB to 2GB), SDHC (4GB to 32GB)
- Storage class
- Max 32GB
- File format
- FAT16/FAT32/EX-FAT/NTFS
- Power
- AC 100V to 240V, 50/60Hz
- Power Consumption
- 30W
- Operating Temperature
- 41 to 95 Degree F (5 to 35 Degree C)
- Frequency response
- 20Hz to 20kHz, +/-0.5dB (JEITA)
- THD
- 0.03% or less (1kHz, JEITA)
- S/N ratio
- 96dB or more (JEITA)
- Dynamic range
- 96dB or more (JEITA)
- Channel separation
- 89dB or more ( JEITA)
- Dimensions (W x H x D)
- 19 x 1.73 x 11.05" (482.6 x 44 x 280.7mm)
- Weight
- 5.82 lbs (2.64kg)
|
Acknowledging the golden era of Hi-Fi with its beautiful design, the A-S1200 boasts an impressive array of the latest technology to accurately deliver an emotional, purely musical sound.
Nostalgic Hi-Fi design. Today's Hi-Fi technology
A nod to the past with the latest technology for a purely musical sound.
Emotion
Understanding music is to understand the emotion upon which music is created - the passion and story behind the music that drives artists to create. With unmatched experience in every facet of music creation, embedded deep in the Yamaha DNA is an intimate understanding of the emotional essence of music and music creation. Conveying the artists' emotion through our Hi-Fi equipment is a fundamental component of the Yamaha design philosophy.
>Toroidal Transformer
Usually reserved for flagship Hi-Fi components, the A-S1200 benefits from the technical proficiency and absolute musicality of a toroidal transformer. Combined with an array of high-end Hi-Fi features and components, the toroidal transformer assists in ensuring the musical emotion is conveyed to the listener.
Gorgeous Level Meters
The level meters are both a nod to the nostalgic era of Hi-Fi, while simultaneously demonstrating the return of pure Hi-Fi for today's discerning enthusiast. Visually presenting the dynamics and pulse of the music, the level meters imbue a warm feeling through their softly illuminated LEDs.
Openness
An open sound stage presents the listener with a musical experience that is similar to being at the live performance. True Hi-Fi delivers this openness in the sound, transforming the listeners' musical experience, bringing them closer to the artist.
Thick Wires for Ground Connection
Our low Impedance concept, aided by the thick wires for ground connection, is critical for componentry adopting the badge of premium Hi-Fi. This Yamaha design concept begins in our premium Hi-Fi components with the A-S1200, helping to present an open, natural sound stage, bringing the artist and listener closer together.
Original Speaker Terminals
Cut directly from pure brass, the luxurious speaker terminals comfortably fit the human hand for effortless tightening, achieving a highly secure connection.
Groove
Connection with the music is achieved with the underlying groove and rhythm. A true representation of the music lets the listener feel the groove, and therefore not just hear the music but feel the story behind the music.
Mechanical Ground Concept
The A-S1200 adopts a Mechanical Ground Concept, inherited from both the A-S2200 and A-S3200. The concept begins with the bolts of the feet welded directly to the main chassis, followed with the large heat sink, power transformer and block capacitors also directly bolted to the chassis. Through this design, unwanted vibration is avoided, achieving expressive and rhythmic bass, presenting the 'Groove' of the music to the listener.
Chrome-Plated Iron Feet
Completing the rigidity of the amplifier are the heavy-duty chrome-plated iron feet.
- High quality components delivering exceptional musical expression
- Toroidal power transformer with enormous energy for a pure musical sound
- Gorgeous level meters convey dynamics and music pulse with a nod to the nostalgic Hi-Fi era
- Floating balanced power amplifier
- Mechanical ground concept maximizes rigidity for expressive and rhythmic bass
ColorBlackRated output power 2-channel driven8Ohm: 90 W + 90 W
4Ohm: 150 W + 150 W (20 Hz to 20 kHz, 0.07% THD)Dynamic power8Ohm: 105 W + 105 W
6Ohm: 135 W + 135 W
4Ohm: 190 W + 190 W
2Ohm: 220 W + 220 WIEC output power8Ohm: 95 W + 95 W (1 kHz, 0.07% THD)Maximum effective output power8Ohm: 120 W + 120 W
4Ohm: 190 W + 190 WPower bandwidth 2-channel driven8Ohm: 10 Hz to 50 kHz (0.1% THD, 45 W)Damping factor8Ohm: 250 or higher(1 kHz)Input sensitivityPHONO (MC): 150 micro Vrms / 50Ohm
PHONO (MM): 3.5 mVrms / 47 kOhm
CD (or similar): 200 mVrms / 47 kOhm
MAIN IN: 1 Vrms / 47 kOhmMaximum inputPHONO (MC): 2.0 mVrms
PHONO (MM): 50 mVrms
CD (or similar): 2.80 VrmsRated output voltageLINE 2 OUT: 200 mVrms / 1.5 kOhm
PRE OUT: 1 Vrms / 1.5 kOhmHeadphone jack rated output power25 mW + 25 mW (1 kHz, 32 Ohm, 0.2% THD)Frequency response5 Hz to 100 kHz: +0 / -3 dB
20 Hz to 20 kHz: +0 / -0.3 dBDeviations from RIAA equalizerPHONO (MM/MC): +/-0.5 dBTotal harmonic distortion plus noise2-channel driven: PHONO (MC) - LINE 2 OUT, 1.2 Vrms: 0.02%
PHONO (MM) - LINE 2 OUT, 1.2 Vrms: 0.005%
CD (or similar) - SPEAKERS OUT, 50 W/8Ohm: 0.035%
Signal-to-noise ratioPHONO (MC): 90 dB
PHONO (MM): 96 dB
CD (or similar): 110 dBResidual noise50 micro VrmsChannel separationPHONO (MC): 66/77 dB or higher
PHONO (MM): 90/77 dB or higher
CD (or similar): 74/54 dB or higherTone control characteristicsBASS: Boost/cut: 50 Hz / +/-9 dB
Turnover frequency: 350 Hz
TREBLE: Boost/cut: 20 kHz / +/-9 dB
Turnover frequency: 3.5 kHzPower supplyAC 120 V, 60 HzPower consumption350 WStandby power consumptionOFF mode: 0.1 W
Standby mode: 0.2 WDimensions (W x H x D)17.13 x 6.13 x 18.25" (43.49 x 15.57 x 46.35cm)Weight48.5 lbs (22kg)
|
Equipped with the 6th generation of Direct Energy HD Amplifier, the SC-LX704 is worthy of being your home cinema's centerpiece, and an ideal combination for Pioneer's flagship universal disc player. Two ES9026PRO DACs ensure quality audio reproduction, while MCACC Pro Auto Room Tuning technology with Full Band Phase Control brings out the best from 3D surround sounds of IMAX Enhanced, Dolby Atmos, and DTS:X. Enjoy rich, vibrant sound with PQLS jitterless transmission. The new Audio Exclusive Mode and AV Direct Mode enhance detailed sound reproduction by turning off the unused functions to eliminate unwanted noise.
Direct Energy HD Class D Switching Amplifier
Continuously evolving throughout the years, Pioneer's Direct Energy HD Amp has now reached the 6th generation. New power coils are adopted for the ideal speaker drive, as well as new custom film capacitors co-developed with Shinyei Capacitor for the ultimate sound. The power supply and patterning has been developed through repeated tuning. Also, the entire transmission path from the pre stage to the power stage has been changed to balanced circuitry, to transmit noise-free high-quality signals to the power stage.
MCACC Pro Auto Room Tuning
MCACC Pro, the pinnacle of Pioneer's auto room tuning technology, analyzes the phase and group delay characteristics to precisely control phase differences between speakers. MCACC Pro corrects phase differences in all ranges and all channels, from phase difference in the original audio material to the sound emitted from the speakers. Required microphone included.
IMAX Enhanced MODE
IMAX digitally re-mastered content for the home environment is created to provide the same sharp 4K HDR images and powerful sound just as the filmmaker intended. Pioneer Elite's IMAX Mode is meticulously optimized to play digitally remastered content to deliver the best viewing and listening experience on Earth.
ESS 384 kHz/32-bit DAC
Two 384 kHz/32-bit ESS DACs (ES9026PRO), same as the ones used for Pioneers PD-70AE SACD player, are used for all channels. With extremely precise D/A conversion and high S/N ratio, the DAC provides powerful sound full of rich details.
Dolby Atmos
You can reproduce object-oriented sound in smooth, curving movements, or the realistic three-dimensional movement overhead by the top speakers.
DTS:X
Can automatically adapt the audio to the existing channels and speaker system, no specific speaker layout is required.
Full Band Phase Control
Pioneer's Phase Control technology effectively eliminates phase lag and significantly improves the multi-channel sound without any extra operation. Furthermore, The Full Band Phase Control technology focuses on the group delay in the speaker network filter, and adjusts the phase of each unit as well as the group delay for each speaker. Multi-range speakers gain the sound coherence of full-range speakers, while retaining the wide frequency range advantage. In an environment where the phase of all units and all channels are precisely controlled, a remarkably clear sound location with a surrounding feel is achieved. In combination with MCACC Pro, the ideal multi-channel reproduction environment can be created, which faithfully replicates object audio and the intention of the original content developer.
PQFA Jitterless Sound Processing for Network/USB
With PQFA (Precision Quartz File-based Audio), clocks are available for each stage of input, digital signal processing, and D/A conversion, and the shorter path prevents jitter from occurring. Additionally, a high-precision clock IC (OSC) is used to realise D/A conversion with significantly less jitter.
PQLS Jitterless Sound Transmission
With the precision quartz controller on the AV receiver, Precision Quartz Lock System (PQLS) eliminates distortion caused by timing errors. It controls the amount of audio signals from the AV receiver to the Pioneer universal disc player connected via HDMI, giving the best possible digital-to-analog conversion.
Audio Exclusive Mode
Interference from video signals is eliminated by turning off the video signal path via HDMI. You can enjoy detailed sound, full of spatial feel.
AV Direct Mode
The feature turns off the network functions to suppress digital noise within the AV receiver, and improves sound quality for analog playback, digital input, HDMI playback etc. Mode 1 turns off the network module operation clock, while Mode 2 shuts down the network power completely for more superior sound.
Works with Alexa
Works with Alexa makes you control SC-LX704 with your voice via Alexa-enabled device such as the Amazon Echo, to play, pause, and skip titles or control the volume. You can enjoy the music via streaming service such like Amazon Music by selecting song title, artist name, release year, and genre.
Ready for 4K HDR entertainment
Enjoy support for HDR (High Dynamic Range) video including HDR10, HLG, Dolby Vision, and BT.2020. The 4:4:4 color space is also supported. Six HDMI inputs, ARC-ready MAIN OUT, and SUB OUT pass 4K/60p and HDR video from player to compatible TV and projector and all terminals are HDCP 2.2 compliant.
High-Performance AC Cable
Included detachable OFC power cable contributes to superior sound.
Anti-Standing Wave Insulators
Features a special form with no parallel sides inside to prevent cavity resonance. This makes the sound localisation, tone, and scale clearer, while also contributing to seamless connection between the channels and improved response to quick sound.
- Direct Energy HD Amplifier
- MCACC Pro Auto Room Tuning
- IMAX Enhanced
- ESS 384 kHz/32-bit DAC
- Dolby Atmos/Dolby Surround Upmixing
- DTS:X/DTS Neural:X Upmixing
- Full Band Phase Control
- 2 Subwoofer Pre-Out
- PQLS Jitterless Sound Transmission
- PQFA Jitterless Sound Processing for Network/USB
- Audio Exclusive Mode
- AV Direct Mode
- Works with Alexa
- Next Generation Video Standard Ready
- Anti-Standing Wave Insulators
- AC Inlet Type Thick Cable
- Amplifier Design
- Class D3 (Direct Energy HD)
- Multi-ch Simultaneous Drive
- 760 W (8ohms, 1 kHz, THD 1 %)
- 4 Ohm Speaker
- Yes
- Channels
- 9.2
- 8 ohms, 1kHz, THD 0.08 %, 2ch Driven FTC
- 135W+135W
- Power Consumption
- 310W/0.2W (Estimated Power Consumption/Network Standby off)
- AirPlay
- Apple AirPlay 2
- Internet Radio
- TuneIn Radio
- Works with the Google Assistant
- Yes (Chromecast built-in)
- FlareConnect for Multi-room Audio
- Yes
- Roon Tested
- Yes
- Streaming Audio From PC/Network
- Yes
- iOS/Android Remote Control APP
- Pioneer Control App
- Works with Alexa
- Yes (Firmware update)
- DTS Play-Fi w/Pioneer Music Control App
- Yes
- Music-Streaming Services Ready
- Amazon Music, Pandora, Spotify, TIDAL, and Deezer Hi-Fi: Yes
- Digital Core DSP Engine
- Digital Quad-Core 32-bit DSP (Cirrus Logic) + Aureus floating- point DSP (TI)
- Audio Processing
- 11.2
- IMAX Enhanced
- Yes
- Dolby Atmos Height Virtualizer
- Yes
- Dolby Digital Plus
- Yes
- DTS-HD Master Audio
- Yes
- HDMI SACD Transfer
- Multi-Channel
- Audio DACs
- 384 kHz/32-bit D/A Conversion with ES9026PRO x 2
- Music File Playback
- 192 kHz/24-bit ALAC, AIFF, FLAC, WAV (RIFF) and 11.2 MHz DSD
- Dolby Atmos
- Yes
- Dolby TrueHD
- Yes
- DTS:X
- Yes
- DTS Neural:X
- Yes
- MCACC
- Yes (Pro)
- Full Band Phase Control
- Yes
- Phase Control
- Yes
- EQ Bands
- 9-Band
- Distance Adjustment
- 0.05'
- Auto Subwoofer Crossover
- Yes
- MCACC Memory
- 3
- Auto Phase Control Plus
- Yes
- Standing Wave Control
- Multi-point (9 points)
- EQ Type
- LR SYMMETRY EQ, FRONT ALIGN EQ, ALL CH ADJUST EQ
- Polarity Check
- Yes
- Auto Surround
- Yes
- Advanced Surround
- 10+1
- Stream Direct
- Yes (Direct, Pure Direct)
- Front Stage Surround Advance
- Yes
- Dialog Enhancement
- Yes
- DSD Music File
- Yes
- Sound Delay (Lip Sync)
- Yes
- Bi-Amp
- Yes
- Advanced Sound Retriever
- Yes (2ch)
- Tone Control
- Multi
- Speaker A/B
- Yes
- 4K Ultra HD Pass-Through
- Ultra HD Pass-through with HDCP 2.3 (4K/60p/4:4:4/24-bit, 4K/24p/4:4:4/36-bit, 4K/60p/4:2:0/36-bit)
- 3-D Ready
- Yes
- HDMI Standby Through
- Yes with Input Switch/Last Memory
- Dolby Vision Compatible
- Yes
- HDMI x.v. Color
- Yes
- Super Resolution
- Yes
- 4K Ultra HD Video Scaler
- Yes (1080p to 4K)
- Audio Return Channel
- Yes (eARC)
- HDR
- HDR10, HLG and BT.2020 Wide Color Gamut Signal Pass-through
- HDMI 36-bit Deep Color
- Yes
- Video Converter to HDMI
- Yes
- HDMI Input/Output
- 7 In (6 Rear, 1 Front)/3 Out
- Bluetooth Built-In
- Bluetooth Wireless Technology (Version: 4.2, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/AAC) Built-in
- Composite A/V Input/Output
- 2 in
- Ethernet Input
- Yes
- Digital Audio Inputs/Output
- 5 in (Optical 3, Coaxial 2)/0 out
- Headphone Output
- Yes
- Phono Input
- Yes
- Wi-Fi Built-In
- Dual Band (5 GHz/2.4 GHz) 802.11ac Compliant Wi-Fi Built-in
- Component Video Input/Output
- 2 in
- USB Terminal
- Front and Rear
- Analog Audio Inputs/Output
- 6 in/0 out
- Pre-Amp Output
- 11.2 ch
- Front A/V Inputs
- USB & HDMI
- AM/FM Presets
- AM/FM Tuner 40 Presets
- On-Screen Display
- User-Friendly GUI with System Setup Menu
- Powered Zone output
- ZONE2/ZONE3
- Zone 2 Sources
- All Audio Sources
- 12 Volt Trigger (Assignable)
- A.B
- IR Serial Remote In/Out
- 2 in/1 out
- Function Rename
- Yes
- Personal Preset
- Yes
- Versatile Speaker Configuration
- Yes
- Auto Power Down
- Yes
- Multi-Room and Source Output
- ZONE2/ZONE3 Pre/Line Out
- Zone 3 Sources
- Analog/Net/Bluetooth/Tuner
- RS-232C
- Yes
- FL Dimmer
- Yes
- Remote
- Yes
- Sleep Timer
- Yes
- Alumium Front Panel
- Yes
- Transformer Stabilizer
- Yes
- 3D Space Frame Construction
- Yes
- Speaker Terminals
- 11 Large
- Advanced Direct Construction
- Yes
- Dimensions (W x H x D)
- 17-1/8 x 7-5/16 x 17-5/16 inches (435 x 185 x 440mm)
- Weight
- 40.8 lbs (18.5kg)
|
Acknowledging the golden era of Hi-Fi with its beautiful design, the A-S1200 boasts an impressive array of the latest technology to accurately deliver an emotional, purely musical sound.
Nostalgic Hi-Fi design. Today's Hi-Fi technology
A nod to the past with the latest technology for a purely musical sound.
Emotion
Understanding music is to understand the emotion upon which music is created - the passion and story behind the music that drives artists to create. With unmatched experience in every facet of music creation, embedded deep in the Yamaha DNA is an intimate understanding of the emotional essence of music and music creation. Conveying the artists' emotion through our Hi-Fi equipment is a fundamental component of the Yamaha design philosophy.
>Toroidal Transformer
Usually reserved for flagship Hi-Fi components, the A-S1200 benefits from the technical proficiency and absolute musicality of a toroidal transformer. Combined with an array of high-end Hi-Fi features and components, the toroidal transformer assists in ensuring the musical emotion is conveyed to the listener.
Gorgeous Level Meters
The level meters are both a nod to the nostalgic era of Hi-Fi, while simultaneously demonstrating the return of pure Hi-Fi for today's discerning enthusiast. Visually presenting the dynamics and pulse of the music, the level meters imbue a warm feeling through their softly illuminated LEDs.
Openness
An open sound stage presents the listener with a musical experience that is similar to being at the live performance. True Hi-Fi delivers this openness in the sound, transforming the listeners' musical experience, bringing them closer to the artist.
Thick Wires for Ground Connection
Our low Impedance concept, aided by the thick wires for ground connection, is critical for componentry adopting the badge of premium Hi-Fi. This Yamaha design concept begins in our premium Hi-Fi components with the A-S1200, helping to present an open, natural sound stage, bringing the artist and listener closer together.
Original Speaker Terminals
Cut directly from pure brass, the luxurious speaker terminals comfortably fit the human hand for effortless tightening, achieving a highly secure connection.
Groove
Connection with the music is achieved with the underlying groove and rhythm. A true representation of the music lets the listener feel the groove, and therefore not just hear the music but feel the story behind the music.
Mechanical Ground Concept
The A-S1200 adopts a Mechanical Ground Concept, inherited from both the A-S2200 and A-S3200. The concept begins with the bolts of the feet welded directly to the main chassis, followed with the large heat sink, power transformer and block capacitors also directly bolted to the chassis. Through this design, unwanted vibration is avoided, achieving expressive and rhythmic bass, presenting the 'Groove' of the music to the listener.
Chrome-Plated Iron Feet
Completing the rigidity of the amplifier are the heavy-duty chrome-plated iron feet.
- High quality components delivering exceptional musical expression
- Toroidal power transformer with enormous energy for a pure musical sound
- Gorgeous level meters convey dynamics and music pulse with a nod to the nostalgic Hi-Fi era
- Floating balanced power amplifier
- Mechanical ground concept maximizes rigidity for expressive and rhythmic bass
ColorSilverRated output power 2-channel driven8Ohm: 90 W + 90 W
4Ohm: 150 W + 150 W (20 Hz to 20 kHz, 0.07% THD)Dynamic power8Ohm: 105 W + 105 W
6Ohm: 135 W + 135 W
4Ohm: 190 W + 190 W
2Ohm: 220 W + 220 WIEC output power8Ohm: 95 W + 95 W (1 kHz, 0.07% THD)Maximum effective output power8Ohm: 120 W + 120 W
4Ohm: 190 W + 190 WPower bandwidth 2-channel driven8Ohm: 10 Hz to 50 kHz (0.1% THD, 45 W)Damping factor8Ohm: 250 or higher(1 kHz)Input sensitivityPHONO (MC): 150 micro Vrms / 50Ohm
PHONO (MM): 3.5 mVrms / 47 kOhm
CD (or similar): 200 mVrms / 47 kOhm
MAIN IN: 1 Vrms / 47 kOhmMaximum inputPHONO (MC): 2.0 mVrms
PHONO (MM): 50 mVrms
CD (or similar): 2.80 VrmsRated output voltageLINE 2 OUT: 200 mVrms / 1.5 kOhm
PRE OUT: 1 Vrms / 1.5 kOhmHeadphone jack rated output power25 mW + 25 mW (1 kHz, 32 Ohm, 0.2% THD)Frequency response5 Hz to 100 kHz: +0 / -3 dB
20 Hz to 20 kHz: +0 / -0.3 dBDeviations from RIAA equalizerPHONO (MM/MC): +/-0.5 dBTotal harmonic distortion plus noise2-channel driven: PHONO (MC) - LINE 2 OUT, 1.2 Vrms: 0.02%
PHONO (MM) - LINE 2 OUT, 1.2 Vrms: 0.005%
CD (or similar) - SPEAKERS OUT, 50 W/8Ohm: 0.035%
Signal-to-noise ratioPHONO (MC): 90 dB
PHONO (MM): 96 dB
CD (or similar): 110 dBResidual noise50 micro VrmsChannel separationPHONO (MC): 66/77 dB or higher
PHONO (MM): 90/77 dB or higher
CD (or similar): 74/54 dB or higherTone control characteristicsBASS: Boost/cut: 50 Hz / +/-9 dB
Turnover frequency: 350 Hz
TREBLE: Boost/cut: 20 kHz / +/-9 dB
Turnover frequency: 3.5 kHzPower supplyAC 120 V, 60 HzPower consumption350 WStandby power consumptionOFF mode: 0.1 W
Standby mode: 0.2 WDimensions (W x H x D)17.13 x 6.13 x 18.25" (43.49 x 15.57 x 46.35cm)Weight48.5 lbs (22kg)
|
The Discovery Series DS-A101 Wireless Integrated Amplifier
80-Watt-per-channel wireless control amp with DSP
The versatile and powerful Discovery Series DS-A101-G Wireless Integrated Amplifier is also the perfect complement to the Discovery Music Server. Together, they open up an unlimited vista of music where wireless convenience meets state-of-the-art sound. ELAC's innovative smartphone application provides the tools for system setup, including sophisticated DSP, optimizing your subwoofer's crossover frequency and room EQ.
This is one versatile integrated amplifier, with outstanding performance and feature-rich control flexibility. Once you experience the Discovery-especially with the new Debut or Uni-Fi loudspeakers-your world of sound just might be altered forever. Discovery does it all, at an affordable price.
An integrated amplifier for todays world.
Roon Ready, Spotify Connect, Dolby Digital Decoding, Wi-Fi, and Room EQ are only the beginning.
Discover power, performance, convenience and value.
The new DS-A101-G integrated amplifier strikes the perfect balance of high quality audio reproduction, features and value. The small form factor allows for easy placement while still providing technologies and convenience not found on competing products.
The BASH amplification solution
At their heart is a brand new BASH Tracking Amplifier delivering 80 Watts per channel into either 4 or 8 ohm speakers. This new amplifier uses a modulated switched mode power supply allied to a conventional class AB amplifier. Switching at more than 400,000 times per second, the supply tracks the incoming audio signal to ensure that the Class AB amplifier gets only the voltage necessary (with a little headroom) to cope with today's dynamic movie and music content, thus maximizing the efficiency and potential of the amplifier.
App-rich control flexibility
ELAC's free iOS and Android app allows users to fully control and set up their system. The app includes innovative features not found on any other products in this class-anywhere
ABC Technology (Auto Blend & Calibrate)
The companion IOS and Android app measures the near-field response of main speakers and subwoofer, then pinpoints the subwoofer's optimal crossover frequency. Auto Blend results in the perfect integration of clean, articulate bass. Room Calibration precisely tailors your system for flattest frequency response across the audio spectrum, optimized for your listening position and environment
The Center of your Living Room
With built-in Dolby Digital Decoding, the Discovery Integrated amplifier has been designed to sit at the heart of your entertainment system. Simply connect the audio output from your TV to the Discovery Integrated Amplifier and experience your favorite movies or TV shows like never before.
- 2x 80 Watt Amplifier
- Wi-Fi and Bluetooth Built-In
- Spotify, Roon and Airplay Support
- Dolby Digital Decoding
- Auto Room EQ
- Amplifier
- BASH Digital Fidelity Tracking Amplifier
- Power Output Continuous
- 2x 80 Watts 2 channels driven into 4 ohms @ 1kHz
2x 40 Watts 2 channels driven into 8 ohms @ 1kHz
2x 70 Watts 2 channels driven into 2 ohms @ 1kHz
- Power Output Burst (CEA 2010*)
- 120 Watts 1 channel driven into 4 ohms @ 1kHz
65 Watts 1 channel driven into 8 ohms @ 1kHz
170 Watts 1 channel driven into 2 ohms @ 1kHz
- Power and THD+N, 1kHz
- 4 ohms 70 Watts @ .07%
8 ohms 40 Watts @ .03%
- Signal-to-Noise Ratio
- (Full Power Digital input): 101dB
- Broadband Frequency Response
- 20Hz to 40kHz +/- 1.8dB
- Analog Inputs
- 2
- Digital Inputs
- 2 total; 1 optical / 1 coaxial (192kHz 24-bit)
- Ethernet
- 1
- Wi-Fi
- Yes
- Subwoofer Output
- 1
- Pre-Amp Outputs
- 1 (L/R)
- Bluetooth Audio
- Yes
- Audio Decoding
- Dolby Digital
- Streaming Services
- Discovery, Roon Ready, Spotify Connect, AirPlay, Bluetooth, DLNA
- Display
- OEL
- App Control
- Yes, iOS and Android control app
- Room Correction
- ABC (Auto Blend & Calibrate)
- Power Consumption
- Power Off 120Vac: .86W / Auto Off 120Vac: 5.45W
- Dimensions (W x H x D)
- 8.37 x 2.12 x 11.62" (21.25 x 5.38 x 29.51cm)
- Weight
- 4.80 lbs (2.17kg)
| The Yamaha A-S701 Integrated Silver Amplifier is designed for pure sound quality and outstanding drive power. An integrated amplifier with the advantage of analog and digital inputs.
High Quality Circuit Design Based on the ToP-ART (Total Purity Audio Reproduction Technology) Concept
The amplifier design technology from Yamaha is called ToP-ART, which features an input to output with a direct symmetrical design. ToP-ART design and ART Base ensure optimum sound when processing and transmitting the audio signal. The signal is simple and direct, so therefore it is less likely to be affected by noise and distortion. The left and right channels are organized in a straight, symmetrical layout for the highest signal purity. In addition, the ART (Anti-Resonance and Tough) Base bottom chassis and a solid center bar provide high rigidity support and dampers vibration. These design innovations contribute to this amplifier's rich audio reproduction with abundant musicality.
High Quality Parts for Outstanding Audio Performance
Notice the custom-made power transformer, custom-made block capacitors, two direct signal path speaker relays, one point grounding system, extruded aluminum heat sinks and other top-quality parts to effortlessly handle demanding audio conditions. The quality of each individual part, as well as how they work together, basically determines the sound quality of this component. Yamaha uses only very high quality parts, carefully selected and tested for their sound properties.
Created by Rich Experience, Tradition and High Technological Expertise
Yamaha, with a long history of over 125 years as a musical instrument maker, also has a high reputation for Hi-Fi components. The A-S301 is created by taking advantage of this rich experience and high technological expertise. Based on the concept of "Natural Sound" for reproducing all music as it really sounds, this amplifier is built with scrupulous care from its circuit design to basic sound production
CD Direct Amplification and Pure Direct Mode for Greater Sound Purity
With a straight connection to the CD input, CD Direct Amplification maximizes the CD source's signal to noise ratio. Additionally, engaging the Pure Direct mode causes the music signals to travel the shortest possible circuit route, bypassing the buffer amp, the tone, loudness and balance controls to virtually eliminate any signal degradation for the purest sound quality..
Continuously Variable Loudness Control
The A-S301 also features a new analog loudness control on the front panel that uses electronic volume for higher sound quality, which lets you adjust the loudness effect as desired. Separate from the overall volume, this controls the balance of the low and high frequencies, providing full tonal range at any volume level by compensating for the natural loss in the human ear at soft levels.
Gold Plated Terminals
Gold plated terminals ensure a high quality connection that prevents signal loss. The A-S501 has gold plated speaker and input terminals.
Digital Audio Input for TV and/or Blu-ray Disc Player
The A-S301 is equipped for digital audio inputs with an optical and digital coaxial input terminal. The optical is for receiving audio from a TV and the coaxial for receiving audio from a Blu-ray Disc player. The audio stays in the digital domain, giving you pure, pristine and dynamic sound for all of your entertainment sources.
Connection for YBA-11 Bluetooth Wireless Adapter (Optional Accessory)
With the YBA-11, you'll be able to stream music wirelessly from a Bluetooth compatible mobile phone or a PC. Thanks to the digital coaxial connection and the aptx audio coding algorithm, you will enjoy wireless music streaming with optimum sound quality. You can also conveniently power the YBA-11 via the DC out connection on the rear panel of this amplifier.
Speaker A, B or A+B Selection and Speaker Terminals for Two Systems
You can connect two separate speaker systems and hear them in different rooms at the same time. There are four terminals, so by just rotating a simple selector dial, you can switch between the two pairs of speakers to play the selected source.
Subwoofer Terminal
A terminal for connecting a subwoofer is provided, allowing you to increase the bass output of your system for a more powerful sound with better overall sound quality.
Phono Moving Magnet Input Terminal
You can connect a turntable with a MM phono cartridge to play vinyl records. Get the best of both worlds whether listening to analog vinyl or the latest digital technology.
Simple Yet Sophisticated Design
With a beautiful, simple and unique design inherited directly from Yamaha Hi-Fi audio components, this amplifier also boasts an easy to operate layout. The aluminum front panel has a richly textured silver hairline finish. The control knobs are also of the same luxurious construction as used on top end models.
Remote Control with Clean, Simple Design
The clean, simple design of the remote control provides easy to understand operation with a single hand. The design makes it simple to adjust inputs, volume and more. The unit has a sophisticated looking hairline finish that matches the design of the amplifiers. You can also use the remote to control a Yamaha CD player.
Rotary Encoder Input Selector with LEDs
The rotary encoder makes it quick and easy to select input sources. The luxurious hairline finish offers a nice tactile feeling. LEDs clearly show which source is selected, so you can easily switch sources, even in a dark room.
Auto Power Standby Function
When Auto Power Standby is engaged, the amplifier will automatically shift itself into standby mode when a user function has not been executed in eight hours. This is a great function if you forget to turn the amplifier off and it will help minimize power consumption when the unit is not in use.
This product can only be shipped to U.S. addresses.
- Minimum RMS Output Power
- 8 Ohms: 100 W + 100 W (0.019% THD)
6 Ohms: 120 W + 120 W (0.038% THD)
- High Dynamic Power/Channel
- 140 / 170 / 220 / 290 W at 8 / 6 / 4 / 2 Ohms
- Frequency Response
- 10 Hz - 100 kHz +/- 1.0 dB
- Maximum power per channel
- 1 kHz, 0.7% THD, 4 Ohms: 160 W
- IEC power
- 1 kHz, 0.019% THD, 8 Ohms: 115W
- Power band width
- 0.04% THD, 50 W, 8 Ohms: 10 Hz to 50 kHz
- Maximum Effective Output Power
- 1 kHz, 10% THD, 6 Ohms: 170 W
- Input sensitivity/Input impedance
- PHONO (MM): 3.0 mV/47 kOhmss
CD, etc: 200 mV/47 kOhmss
- Maximum input signal
- PHONO (MM) (1 kHz, 0. 03%THD): 45 mV or more
CD etc. (1 kHz, 0.5% THD): 2.2 V or more
- Output level/Output impedance
- REC OUT: 200 mV/1.0 kOhmss or less
SUBWOOFER OUT: 3.5 V/1.2 kOhmss
- Phones jack rated output/Impedance
- CD, etc. (Input 1 kHz, 200 mV, 8 Ohms: 470 mV/470 Ohms
- RIAA equalization deviation
- PHONO (MM): +/- 0.5 dB
- Channel separation
- CD, etc. (5.1 kOhmss input shorted,1kHz): 65 dB or more
CD, etc. (5.1 kOhmss input shorted,10 kHz): 50 dB or more
- Bass
- Boost/Cut (20 Hz): +/- 10 dB
Turnover frequency: 400 Hz
- Treble
- Boost/Cut (20 Hz): +/- 10 dB
Turnover frequency: 3.5 kHz
- Continuous loudness control
- - 30 dB
- PCM word depth
- 24 bit/16 bit
- Power supply
- AC 120 V, 60 Hz
- Power consumption
- 270 W
- Standby power consumption
- 0.5 W
- Maximum power consumption
- 580 W
- Total Harmonic Distortion (CD to Sp Out)
- 0.019% (50 W / 8 Ohms)
- Signal-to-Noise Ratio (CD)
- 99 dB (input shorted, 200 mV)
- Damping Factor
- 240
- Digital Input
- Yes (optical / coaxial)
- Audio In / Out
- 8 / 2
- Subwoofer Out
- Yes
- Pure Direct
- Yes
- ToP-ART
- Yes
- Switchable CD Direct Amplification
- Yes
- DC out
- Yes
- Standby Power Consumption
- 0.5 W
- Power Management (Auto Power Standby)
- Yes
- Dimensions (W x H x D)
- 17.12 x 6 x 15.25" / 434.84 x 152.4 x 387.35mm
- Weight
- 24.7lbs / 11.20kg
|
Reviews
There are no reviews yet.
