Housed within the gorgeous piano-gloss black enclosure are two horizontally-opposed 12" ultra-long-throw active drivers and two vertically-opposed 15" x 13" planar infrasonic radiators. This dual-plane, patented† dynamic inertial-balancing preserves and focuses all the energy produced by the transducers in order to more effectively move the air in the room, rather than wasting energy moving the box. It also enables you to hear all the fine subtle details in your recordings.
GoldenEar's best subwoofer, the new SuperSub™ Series models are ultra-high-performance yet amazingly compact subwoofers that incorporate many recently developed unique and advanced technologies and components. The goal was to create beautifully styled, finely finished, reasonably sized subwoofers that could generate very low-frequency pressure waves of extremely high amplitude, while delivering accurate and precise low-frequency performance that is both highly impactful and extremely musical.
In order to achieve this, the SuperSubs, GoldenEar's best subwoofer series, incorporates a unique, patented* 360 degree dual-plane inertially-balanced driver and sub-bass radiator topology, combined with a very advanced electronics package. With two active drivers separated horizontally in space, as well as two passive radiators separated vertically, the driver-to-room coupling is distributed much more smoothly, for in-room bass performance that can’t typically be achieved with a single subwoofer.
The electronics packages that drive the SuperSubs' fully balanced array are a 1600 watt (XXL) and 1400 watt (X) Class D Digital amplifiers whose design is based on the technology originally developed for the GoldenEar Triton One tower. Features include: Discrete multi-band limiting, phase-perfect equalization, fully balanced and advanced reconstruction filters and a strong focus on keeping latency to an absolute minimum. Input facilities include a direct-coupled, unfiltered LFE input for home theater, or stereo Left/Right low-level inputs with low-pass for two-channel setups. Sonically, the result of all this technology is a rock-solid bass response that is both exceptionally fast and tuneful for music and extraordinarily deep and powerful, in order to effortlessly reproduce the most extreme movie sound effects.
- Two 12" long-throw high-output bass drivers
- Two 15" x 13" quadratic planar infrasonic radiators
- 1600 Watt ForceField digital amplifier
- LFE Line-Level Input: Unfiltered (no low pass), direct-coupled
- Right/Left Line-Level Input: Variable Low-Pass from 40 Hz – 150 Hz
- Fuse Size: 8-amp 250-volt slow blow fuse (110-volt version) / 6.3-amp 250-volt slow blow fuse (240-volt version)
|
The compact, 14" Tall Aon 3 Bookshelf Monitor incorporates a 7", High-Definition, Multi-Vaned Phase Plug (MVPP™), cast-basket Mid-Bass Driver, coupled to two 8" Inertially-balanced side-mounted Low-Frequency Radiators and the GoldenEar High-Velocity Folded Ribbon Tweeter (HVFR™).
The BRX, Aon 2 and 3 bookshelf speakers are exceptionally compact, ultra-high-performance speakers that were originally developed for use as nearfield monitors in professional mixing applications. The design goal was to produce modestly-sized shelf or stand-mountable bookshelf speakers that would achieve accurate high-definition sonic reproduction, with superb three-dimensional imaging, comparable to that achieved by GoldenEar’s award-winning Triton Towers. The new BRX was specifically developed incorporating technology developed for the Triton Reference in order to achieve reference level performance. Although they don’t have quite the awe-inspiring bass of the floor-standing Tritons, great care has been taken, and extensive technology has been incorporated, to ensure that the BRX and Aons can deliver a remarkably satisfying full range listening experience without the need for a separate subwoofer.
Both the BRX and Aon models incorporate GoldenEar-designed cast-basket bass/midrange drivers with technology derived from the midrange units developed for the Tritons. The BRX driver is actually almost exactly the same as the 6" driver used in the Triton Reference. In addition, they all use extraordinary and costly High Velocity Folded Ribbon (HVFR™) high frequency radiators. And the BRX uses the same tweeter developed for the Triton Reference. Lastly, each BRX and Aon model utilizes two side-mounted planar low-frequency radiators in an inertially balanced configuration in order to properly load the bass/midrange drivers for an open, box-less midrange, while also contributing to their’ remarkably extended bass for such small enclosures.
| IsoAcoustics' Aperta Support plate can increase the surface area of speaker stand tops to accommodate the length and width of isolation stands or speakers. IscoAcoustics recommends and provides double sided tape to fasten their support plate but they can also be drilled to any surface if desired. |
S4 speaker stands are the perfect addition to your desktop speaker setup. With 16 of upward tilt, they ensure you experience the full range of frequencies your speakers have to offer. Each stand features foam padding to reduce vibration when you have the sound cranked up, and includes a mounting hole and 1/4"-20 screw to secure your YU4 or other compatible speakers in place.
- Get the most out of your speakers by tilting them toward your ears, ensuring you never miss out on those higher frequencies.
- Improve stabilization by securing YU4 or other compatible speakers in place with the provided 1/4"-20 screw.
- Foam padding on the top and bottom of each stand helps to maintain stability and reduce undesirable resonance.
Features
Desktop Stands: Pair the Kanto S4 desktop stands with your Kanto YU4 powered desktop speakers or another brand of desktop speakers of similar size and weight.
- Overall Dimensions: 5.5625" (w) x 2.0625" (h) x 7.9375" (d)
- Top Plate Dimensions: 3.875" (w) x 6.25" (d)
- Base Dimensions: 5.5625" (w) x 7.9375" (d)
- Weight Capacity: up to 8 lbs
- Your compatible desktop speakers should measure 5" to 7" (w) x 7" to 10" (d), and weigh no more than 8 lbs.
- 1/4"-20 screws are included to secure the Kanto YU4 speakers to the desktop stands; other brands of similar size speakers will not use these screws.
16° Vertical Tilt: With 16° of vertical tilt, the S4 desktop speaker stands angle your speakers towards your ears, ensuring you experience the full range of frequencies they have to offer.
Vibration Resistant: The S4 desktop speaker stands feature multiple areas of foam padding to maintain stability and reduce vibration.
Available In A Variety Of Colors: The S4 desktop stands are available in a variety of colors ( black, white, aluminum, brass, copper, or stainless steel) to compliment your decor
|
The Motion ultra-slim SLM XL features four passive radiators for amazing, controlled bass performance.
- The dual 4-inch, ultra-slim fiber cone woofers and four 4-inch passive bass radiators, paired with a Folded Motion tweeter create stunning acoustical alchemy all from a thin profile.
- The drivers are held securely in place by a solid, black-anodized brushed aluminum baffle under the grille.
| The EFX is a slim, on-wall hybrid electrostatic loudspeaker, featuring XStat™ technology, dramatically reducing cabinet size, yet establishing new standards for efficiency, dynamics and precision.
- Housed within a radical, ultra-ridged extruded aluminum AirFrame™, the EFX's new CLS XStat transducer builds upon the legacy of MartinLogan's electrostatic heritage with the incorporation of advanced vacuum bonding and MicroPerf stat panels, providing even greater efficiency and precision.
- Proprietary Vojtko filtering technology is utilized for EFX's electrostatic transducer. This audiophile quality network, derived from the CLX, is carefully hand-built using precision point-to-point wiring, polypropylene capacitors, massive air-core coils, and a custom wound E-I core transformer.
|
