4K Ultra HD HDMI Support.
Providing complete compatibility with the latest HDMI standards, this AV receiver delivers transmission of 4K video at 60 frames/second pass-through. It also supports HDR (high dynamic range) Video including Dolby Vision and Hybrid Log-Gamma which provides incredible contrast, smooth tone and rich, bright colors—giving you full, high-definition enjoyment with an exceptionally realistic and natural picture quality.
Experiences Expanded: CINEMA DSP.
Exclusive Yamaha CINEMA DSP technology supports playback of HD Audio (Dolby® TrueHD, DTS-HD Master Audio™, etc.), providing natural and expansive sound imaging. CINEMA DSP transforms the dynamics of the listening environment, with acoustic reproduction of famous venues such as the Bottom Line, Roxy Theater, and European cathedrals—letting you experience their ambience right in your room.
Every Room Is Different: Easy Sound Optimization with YPAO.
YPAO (Yamaha Parametric room Acoustic Optimizer) analyzes the room acoustics and your system, then precisely adjusts various audio parameters to provide the best sound for your room. By placing the supplied microphone at your listening position and switching YPAO on, the system is automatically tuned for optimum performance in your home.
Built for Performance: Discrete Amp Configuration.
The RX-V385 was designed with a strong focus on achieving exceptionally high-clarity sound. It employs a discrete amp configuration and a low-jitter PLL circuit, which contributes to its excellent audio performance.
Designed for Sound: Bi-Amp Connection.
The RX-V385 offers the ability to bi-amp compatible front speakers (L, R), which drives the high and low ranges with independent amplifiers. In addition to providing greater power, it also prevents interference between the high and low sounds, further improving the sound of the front speakers (trade with surround speakers).
Feel Your Lows: Rich Bass Reproduction.
This exclusive low-range enhancement technology delivers richer bass than you would expect from smaller sized speakers while maintaining good localization and sound balance even with compact front speakers. When a subwoofer is used, it improves the volume of the entire low range of the speaker system, not only the front speakers, but also enhancing the bass from the subwoofer. You'll enjoy video and music with sound that has exceptional power and presence.
Full Resolution, Total Immersion: eARC (Enhanced Audio Return Channel).
Unlock the full potential of your 4K content. Enhanced Audio Return Channel (also known as eARC) is the next generation of ARC – available in the industry-leading AV receivers from Yamaha.
eARC delivers full-resolution, multichannel audio formats such as Dolby® TrueHD and DTS-HD® through your existing HDMI connection, giving you the most realistic surround sound experience for immersing yourself in your favorite movies and moments.
Virtual Surround.
Even when it is impossible to install surround speakers behind the listening position, you can enjoy virtual 5-channel surround sound with all of the speakers placed in the front of the room.
Configured Settings: Scenes.
Pressing a SCENE button powers on the AV receiver or remote selects the input source and DSP mode. You can re-set the buttons for different sources by selecting a source and DSP mode, then pressing a SCENE button for more than three seconds.
An Easy Install.
Use this special app and get expert assistance with cable connections between the AV receiver and source devices. It even guides you through various other settings such as speaker connections, TV and source device connections and power amplifier assignments.
Go Green: ECO Mode.
When ECO mode is turned on it can reduce power consumption by about 20 percent*, thanks to an advanced energy saving design. *Compared to power consumption when ECO mode is off (Yamaha measurement).
- Channel
- 5.1
- Rated Output Power
- 100W (8Ohms, 0.9% THD) (1kHz, 1ch driven)
70W (8Ohms, 0.09% THD) (20Hz-20kHz, 2ch driven)
- Maximum Effective Output Power
- 145W (6Ohms, 10% THD) (1kHz, 1ch driven) (JEITA)
- Dynamic Power / Ch
- 110 / 130 / 160 / 180W (Front L/R, 8/6/4/2 ohms)
- Cinema DSP
- Yes
- DSP Programs
- 17
- Dialog Level Adjustment
- Yes
- SILENT Cinema / Virtual Cinema DSP
- Yes (Virtual CINEMA FRONT)
- Dolby TrueHD
- Yes
- Dolby Digital Plus
- Yes
- DTS-HD Master Audio
- Yes
- File Format
- MP3 / WMA / MPEG-4 AAC / WAV: up to 48 kHz / 16-bit
- Compressed Music Enhancer
- Yes (including enhancer for Bluetooth)
- YPAO Sound Optimization
- Yes
- Adaptive DRC (Dynamic Range Control)
- Yes
- Initial/Maximum Volume Setting
- Yes
- Audio Delay
- Yes (0-500ms)
- DA Converter
- 3x Burr-Brown 384kHz / 32-bit DAC
- 4K Ultra HD Pass-through and Upscaling
- Yes (4K / 60p, 4:4:4)
- HDMI 3D Pass-through
- Yes
- HDMI eARC
- Yes (via future firmware update)
- HDMI Audio Return Channel
- Yes
- HDMI Upscaling
- Yes (HDMI to HDMI)
- Deep Color / x.v.Color
- Yes
- 24Hz Refresh Rate / Auto Lip-Sync
- Yes
- HDMI Input/Output
- 4 / 1 (HDCP 2.2, HDR10 / Dolby Vision / HLG and BT.2020 compatible)
- HDMI CEC
- Yes
- USB Input
- USB memory
- Front AV Input
- USB / mini jack
- Digital Audio Input / Output
- Optical: 1/0
Coaxial: 2 / 0
- Analog Audio Input / Output
- 3 (front 1) / 0
- Composite Video Input / Output
- 3 / 1
- Preout
- Subwoofer
- Headphone Output
- 1
- Bluetooth
- Yes (SBC, in and out)
- FM / AM Tuner
- Yes
- On-Screen Display
- Yes (color OSD)
- SCENE
- SCENE (4 sets)
- Remote Control Unit
- Yes
- Standby Power Consumption (IR only)
- <=0.2 W
- Auto Power Standby
- Yes
- ECO Mode
- Yes
- Dimensions (WxHxD)
- 17.12 x 6.37 x 12.37" (43.48 x 16.18 x 31.42cm)
- Weight
- 17 lbs (7.71kg)
|
High sound quality network Hi-Fi receiver with support for DSD 5.6 MHz reproduction. Compatible with MusicCast and packed with network functions. Unlimited enjoyment of many different sound sources including high-resolution sources, smartphones and streaming services. Now with MusicCast, this device can be expanded to deliver wireless multi room audio playback, all controlled by a simple app.
MusicCast
MusicCast makes it easy to bring music to every room in your home wirelessly with playback controlled by a simple app. Start with a MusicCast capable AV receiver in your main entertainment room for the ultimate home theater experience, then add MusicCast speakers, sound bars or Hi-Fi components in other rooms wirelessly.
All Your Content
MusicCast allows you to access your digital music library, streaming music services and Internet radio, as well as Bluetooth sources, your TV sound and external sources attached to your AV receiver, such as a Blu-ray Disc player or CD player.
Bluetooh Output for Convenient Music Streaming
The R-N602 is equipped with Bluetooth functionality to let you easily enjoy wireless music playback from smartphones and other devices. The Compressed Music Enhancer from Yamaha is now optimized for Bluetooth audio transmissions to ensure that your music will have vivid, lively sound quality during wireless playback.
Wireless Music Streaming via Bluetooth or AirPlay
Enjoy music from your smartphone or tablet wirelessly using a Bluetooth connection. You can also use the convenient AirPlay function for wireless music streaming from iPhone or iPads. In addition, a Network Standby mode provides the convenience of having the R-N602 turn on and off automatically.
Streaming Services Offer a Huge Range of Listening Choices
Enjoy support for music streaming services like Pandora, Spotify, Rhapsody and SiriusXM Internet radio means you'll enjoy a wide variety of music content. Furthermore, support for the vTuner radio station database enables sampling of Internet radio broadcasts from around the world.
Enjoy the Entire Spectrum of All Your Favorite Music Sources
The R-N602 is a stereo receiver and network audio player in a single unit. You can use it to easily play audio downloaded from the Internet, stored on a PC or NAS system or enjoy streaming music services and Internet radio (with vTuner). Moreover, the MusicCast app from Yamaha allows you to enjoy your favorite tunes on a smartphone or tablet device via a wireless connection.
Extensive Audio Codec and Format Support
This network stereo receiver is compatible with high-resolution audio codecs such as DSD / AIFF / FLAC / WAV / Apple Lossless. You will enjoy the excellent sound quality of these various high-resolution audio codecs from the USB input on the front panel or from network connected devices. It uses a Burr-Brown 192 kHz / 24-bit DAC that has a firmly established reputation for quality.
USB Digital Connection for iPod and iPhone on the Front Panel
A USB port on the front panel allows convenient connection of an iPod and iPhone, which also charges the iOS device when connected. Because the digital signal from the iPod and iPhone is transmitted directly to the receiver, there is no signal-loss or interference. You get to enjoy the best possible sound quality. In addition, you can use the receiver's remote control unit to operate the iPod and iPhone for basic playback control.
Gapless Playback Compatibility Allows Play without Interruption
Many live and classical albums have no gaps in the music. Gapless playback ensures that there are no pauses between audio files. This provides playback with no interruptions, the way it was meant to be heard.
ToP-ART Sound Quality Design and Highest Quality Parts
Everything in the R-N602 has been built for maximum performance. The internal design utilizes simple, direct transmission of the signals - ensuring optimum separation and elimination of noise and distortion for pure sound reproduction. This includes dual independent power supplies for the two sound sources (analog and digital) as well as original ToP-ART (Total Purity Audio Reproduction Technology) and Art Base chassis construction to fully protect audio signals from noise and vibration. Moreover, all parts and materials have been carefully selected and tested to make sure they are of only the highest quality so that they all work together to provide the absolute best sound possible.
Pure Direct Mode for Greater Sound Purity
Engaging the Pure Direct switch causes the audio signal to bypass the control circuits for bass, treble, balance and the back buffer amp. This improves sound quality while maintaining full output capacity. Shortening the signal route improves sound purity, helping to reproduce even the most delicate musical nuances.
Digital Audio Inputs for TV or Blu-ray Disc Players
The R-N602 is equipped for digital audio inputs with both optical and coaxial terminals. The optical is for receiving audio from a TV and the coaxial for receiving audio from a Blu-ray Disc player. The audio stays in the digital domain, giving you pure, pristine dynamic sound for all your entertainment sources.
Simple Yet Sophisticated Design
With a beautifully simple and unique design inherited directly from Yamaha Hi-Fi audio components, the R-N602 also boasts an easy-to-operate button layout. The aluminum front panel has a richly textured silver hairline finish. The control knobs are also of the same luxurious construction as used on the top-end models. Both inside and out, everything about the R-N602 demonstrates their commitment to superior design quality and ease of use.
ECO Mode and Auto Power Standby
The R-N602 has an ECO mode that reduces power consumption by about 20% and an Auto Power Standby function that you can set to turn the power off after two, four, eight or 12 hours.
This product can only be shipped to U.S. addresses.
- MusicCast wireless multi room audio support
- Bluetooth, built-in Wi-Fi and Wireless Direct
- AirPlay, Pandora, Rhapsody, Spotify, SiriusXM Internet Radio music streaming services
- DSD 2.8 MHz / 5.6 MHz, FLAC / WAV / AIFF 192 kHz / 24-bit, Apple Lossless 96 kHz / 24-bit playback
- Front panel USB connection for digital docking with iPod / iPhone and USB flash drives
- Pure Direct for greater sound purity
- ToP-ART sound quality design with high quality parts
- Digital audio inputs for TV or Blu-ray Disc players
- Phono input (MM)
- ECO mode and Auto Power Standby
- MusicCast
- Yes
- DLNA
- Version 1.5
- File Format
- DSD 2.8 MHz / 5.6 MHz, FLAC / WAV / AIFF 192 kHz / 24-bit, Apple Lossless 96 kHz / 24-bit playback
- Wi-Fi
- Yes (with Wireless Direct)
- AirPlay
- Yes
- Bluetooth
- Yes (AAC)
- Minimum RMS Output Power
- 80 W + 80 W (8 ohms, 20 Hz - 20 kHz, 0.04% THD)
- Maximum Power (4 ohms)
- 105 W + 105 W
- Maximum Power (8 ohms)
- 115 W + 115 W
- High Dynamic Power / Ch (8/6/4/ 2 ohm)
- 105 / 125 / 150 / 178 W
- Frequency Response
- 0 0.5 dB / 0 1.0 dB
- Total Harmonic Distortion (CD to Sp Out)
- 0.015% (40 W / 8 ohms)
- Signal-to-Noise Ratio (CD)
- 100 dB (Pure Direct on, 200 mV)
- Audio In / Out
- 9/2
- USB Input
- iPod / iPhone, USB memory, portable audio player
- Subwoofer Out
- Yes
- FM 50dB Quieting Sensitivity
- 3 microvolts (20.8 dBf)
- FM Signal-to-Noise Ratio (Mono / Stereo)
- 65 dB / 64 dB
- ToP-ART Technology
- Yes
- Standby Power Consumption
- 0.1 W
- Dimensions
- 17-1/8 x 6 x 15-7/16" (43.5 x 15.2 x 39.1 cm)
- Weight
- 21.6 lbs. (9.8 kg)
|
Massive THX sound and Film-Like 8K resolution
Rigorously tested to receive the coveted THX Select Certification, the Onkyo TX-NR6100 7.2-Channel AV Receiver delivers precision sound and images.
With an emphasis on an enhanced gaming experience, own your opponents with HDMI 2.1 enhancements for gamers: 4K/120Hz HDR pass-through enables ultra-fast motion -VRR (Variable Refresh Rate) eliminates lag, stutter, and frame-tearing for fluid gameplay. - ALLM (Auto Low Latency Mode) optimizes latency from source to screen - QFT (Quick Frame Transport) limits lag for a smoother experience.
Setting the bar for reference sound while bringing 8K video to your compatible display over HDMI 2.1, you can enjoy Dolby Atmos and DTS: X soundtracks through your height-enabled surround system or use upmixing and virtualization solutions from DTS and Dolby to create a 3D sound-field from any layout.
Featuring three HDMI outputs and 100 watts of power per channel, the TX-NR6100 AV receiver delivers uncompressed HDMI 2.1 8K 60Hz and 4K/120Hz with HDR over 40 gbps, increasing the bandwidth over its predecessors. This SMART AV Receiver delivers an unparalleled movie, music, and gaming experience to your living room.
HDMI 2.1 with 8K
HDMI 2.1 is the most recent update of the HDMI spec and supports eARC, a range of higher video resolutions and refresh rates including 8K60 and 4K120, and Dynamic HDR formats. 8K delivers a super-immersive viewing experience with 2x the horizontal and vertical resolution of 4K, and 4 times as many pixels; and combined with 60Hz refresh rate enables smooth and sharp viewing of content with high-speed action. HDMI 2.1 with 8K and eARC ensures your system is ready for the clearest and cleanest picture available both now and down the road.
Ultimate 4K Gaming Experience
Own your opponents with HDMI 2.1 enhancements for gamers: 4K/120Hz HDR pass-through enables ultra-fast motion -VRR (Variable Refresh Rate) eliminates lag, stutter, and frame-tearing for fluid gameplay. - ALLM (Auto Low Latency Mode) optimizes latency from source to screen - QFT (Quick Frame Transport) limits lag for a smoother experience.
THX Certified
In 1993, Onkyo became the first consumer electronics brand to be THX-certified. With literally thousands of tests, before earning the THX-certification logo: no matter what input is used, no matter what combination of the many built-in features for the AVR, preamplifier, or amplifier, there can be absolutely nothing added, nothing taken away from the source material.
Built-In Streaming Services
Access to Spotify, TIDAL, Deezer, TuneIn, and Pandora are built into the system. Use dedicated apps (where available) or the free Onkyo Control App for Apple and Android devices to find and play music.
Discrete Zone 2 HDMI Switching
Set up different Ultra High-Definition entertainment options with up to 8K60 resolution* in two different rooms from your Onkyo receiver. Watch a movie in the home theater, while the kids watch cartoons in their playroom.
Smart Home Compatible with Voice Control
Onkyo receivers easily integrate into your existing Smart Home ecosystem, including Apple Airplay, Alexa, Google apps, and more. You get a highly capable and compatible network device that can operate seamlessly in your multi-room ecosystem.
Works with SONOS Certified
This receiver can join your existing Sonos Home Sound System, or be the start of a new one, just by pairing it with a Sonos Port. This works with Sonos Certified AVR offers a best-in-class tie-in to the Sonos ecosystem, waking, changing inputs, and playing at the volume you want using the Sonos Volume-Pass Through feature from the Sonos app.
Bi-Directional Bluetooth Wireless Technology
This Onkyo AVR can send and receive audio via Bluetooth wireless technology. Stream from your device to the receiver using SBC or AAC codecs, or transmit audio playing through the AVR to compatible wireless headphones using SBC, aptX, or aptX HD codecs including 24-bit audio over aptX HD. The improved data transfer capabilities of the latest generation of Bluetooth ensure clear and reliable sound reproduction so you hear your favorite songs just as the recording engineer intended.
Ready for DTS PLAY-FI
DTS Play-Fi allows you to enjoy high-quality music from connected online services, networked media servers, and your device library over Wi-Fi to any number of compatible products using the Onkyo Music Control App for iPad, iPhone, and Android smartphones/tablets. DTS Play-Fi can synchronize the music in every room. Each member of your family can use their own device to listen to their music in a room or group of rooms. DTS Play-Fi lets you structure a comprehensive multi-room ecosystem that satisfies virtually any need.
- 8K with HDMI 2.1 40Gbps (3 ins)
- THX Select Certification
- Discrete Zone 2 Audio and Video
- 210 W/Ch THX Certified Select Dynamic Audio Amplification system
- 5.2.2-channel Dolby Atmos and DTS:X playback
- AccuReflex phase-matching solution for Atmos-enabled speakers
- SMART AV Receiver
- Works with Hey Google or Alexa
- Stream over 5 GHz/2.4 GHz dual-band Wi-Fi supporting the 802.11ac standard
- HDMI Sub/Zone 2 Out for media transmission to a second display
- Send or receive audio via Bluetooth wireless technology
- Refined chassis, HDMI board, DAC, Digital/Analog inputs, power-amp grounds and power lines
- 5.2-ch Main + Powered Zone 2 speakers support synced/independent D/A audio playback
- Zone 2/Zone B line-out
- Power Output (All Channels)
- 210 W/Ch (6 ohms, 1 kHz, 10% THD,1-ch driven)
100 W/Ch (8 ohms, 20 Hz-20 kHz, 0.08% THD, 2-ch driven, FTC)
- Dynamic Power
- 240 W (3 ohms, Front) 210 W (4 ohms, Front)
120 W (8 ohms, Front)
- THD+N (Total Harmonic Distortion+Noise)
- 0.08% (20 Hz-20 kHz, half Power)
- Input Sensitivity and Impedance
- 200 mV rms/47 k-ohms (Line) 3.5 mV rms/47 k-ohms (Phono MM)
- Rated RCA Output Level and Impedance
- 1 V rms/470 ohms (Subwoofer pre-out) 200 mV rms/470 ohms (Zone 2/Zone B line-out)
- Frequency Response
- 10 Hz-100 kHz/+1 dB, -3 dB (Direct/Pure Audio)
- Tone Control
- +/-10 dB, 20 Hz (Bass) +/-10 dB, 20 kHz (Treble)
- Signal-to-Noise Ratio
- 106 dB (Line, IHF-A) 80 dB (Phono, IHF-A)
- Speaker Impedance
- 4-16 ohms
- FM
- 87.5 MHz-107.9 MHz
- AM
- 530 kHz-1,710 kHz
- FM/AM Preset Memory
- 40 stations
- Power Supply
- AC 120 V-, 60 Hz
- Power Consumption
- Operating: 635 W
Idle: 65 W
Standby: 0.1 W
- Dimensions (W x H x D)
- 17.12 x 6.8 x 14.94" (435 x 173.5 x 379.5mm)
- Weight
- 21.7 lbs (9.8kg)
| Supercharge Your Favorite Speakers with MusicCast Streaming Audio
Connect a pair of your favorite speakers to this stereo amp, then use your existing Wi-Fi network to access all of your music from a simple app. Add other MusicCast speakers, sound bars or receivers for wireless multiroom audio playback. Great for use with in-ceiling and outdoor patio speakers.
• High-performance design with premium audio components
• Extremely versatile control and connectivity options
• Access to your music library, Pandora, Spotify, Rhapsody and more
• MusicCast app for Apple iOS and Android devices
• Conveniently slim, can be placed horizontally or vertically
Audiophile Sound, Exquisite Design
The WXA-50 features a solid metal body with an aluminum cover and a slim, compact design that fits just about anywhere. Under the hood, you'll find high-performance components and advanced circuitry that deliver powerful, sonically-pure amplification.
Control at Your Fingertips
Connect the WXA-50 to any pair of traditional wired speakers (bookshelf, tower, in-ceiling or outdoor speakers), then download the free MusicCast app to connect it to your existing home Wi-Fi to create a powerful streaming audio system.
Quickly select sources, browse your music library and control playback right from your smartphone or tablet. You can also control sound EQ settings from the app.
All Your Content
Access streaming music and Internet radio stations, music files on your mobile devices and computers, Bluetooth sources and external sources such as a TV, Blu-ray Disc player or even a turntable.
MusicCast
A single WXA-50 can be used with speakers to create a standalone streaming audio system or multiple units can be used throughout the home. Play different music in each room or get everyone listening to the same thing. It can also be used with other MusicCast speakers, sound bars, AV receivers or Hi-Fi gear, providing more options and versatility than ever before.
Bluetooth and AirPlay
Stream virtually any audio source via Bluetooth as an input to the WXA-50. Bluetooth sources can be redistributed through Wi-Fi to other MusicCast devices. Or stream using AirPlay from an Apple device to a single unit.
Slim, Compact Design
Only 2" tall and 8-3/8" wide, it can be placed horizontally or vertically, allowing it to fit neatly in almost any space.
Rack Shelf Friendly
With the feet removed, the WXA-50 is only 1-5/8" high, allowing it to be placed on a rack shelf within a 1U high rack space. Two units can be placed side-by-side on a 19" wide shelf.
Superior Audio Technology
Yamaha's relentless pursuit of sonic purity is clearly evident in the engineering of the WXA-50. The preamp circuitry uses the same high-performance ESS Digital-to-Analog Converter (DAC) found in high-end Yamaha AV receivers and a proprietary power supply ground configuration prevents sound degradation. A 48-bit digital volume control provides much greater precision and quality than conventional controls. A highly-rigid metal chassis supplies the stability necessary for clear, powerful music reproduction.
High-Resolution Audio
The WXA-50 supports high-resolution audio - including FLAC/WAV/AIFF up to 192 kHz/24-bit, Apple Lossless (ALAC) up to 96 kHz/24-bit and DSD up to 5.6 MHz - for more accurate reproduction of sonic details, presence and atmosphere.
Yamaha Proprietary Sound Processing
The Compressed Music Enhancer greatly improves sound reproduction from smartphones or other compressed sources, like MP3 files. Volume-adaptive EQ automatically adjusts the bass/treble balance according to the volume level. Advanced Bass Extension provides a deeper, richer low-end sound - great for use with compact or in-wall speakers. Direct Mode allows you to play back high-resolution audio sources just as they are, without any processing.
One-Touch Controls
Pressing any button on the front panel turns the unit on and initiates playback of the previously selected source providing quick and easy access to your favorite music.
The WXA-50 also comes with an ultra-slim remote offering six presets, so you can quickly access your favorite Internet radio stations even when your smartphone or tablet's not handy.
Pro-Grade Connectivity and Control
The WXA-50 supports professional-grade features including:
• High-quality binding posts
• Wired Ethernet port
• Wireless off switch
• Optical and analog inputs
• Subwoofer out
• Trigger in/out
• Remote in
Low Power Consumption
The WXA-50 consumes less than two watts of power in standby mode. When the power is on, power consumption is still a low 15 watts. In addition, the Auto Power Standby feature lets you save energy by automatically turning the power off after two, four, eight or 12 hours.
This product can only be shipped to U.S. addresses.
- DLNA
- Version 1.5
- File Format
- MP3, WMA, MPEG-4 AAC, WAV, FLAC, AIFF, ALAC, DSD
- Wi-Fi
- Yes
- AirPlay
- Yes
- Bluetooth
- Yes (SBC / AAC)
- Rated Output Power
- 70 W + 70 W (6 ohms, 20 Hz-20 kHz, 0.06% THD, 2-ch driven)
55 W + 55 W (8 ohms, 20 Hz-20 kHz, 0.06% THD, 2-ch driven)
- Maximum Output Power
- 90 W + 90 W (6 ohms, 1 kHz, 0.9% THD, 1-ch driven)
- Pure Direct
- Yes
- Total Harmonic Distortion (20 Hz-20 kHz)
- 0.02% (SP out)
- Signal-to-Noise Ratio
- 110 dB (Opt / Net / USB / Bluetooth in) / 98 dB (aux in)
- Audio In / Out
- 1/1
- Digital In / Out
- 1 (optical) / 0
- USB Input
- 1
- Ethernet
- 1
- Subwoofer Out
- 1
- Remote In / Out
- 1/0
- Control (Trigger) In / Out
- 1/1
- Standby Power Consumption
- 1.8 W
- Dimensions (W x H x D)
- Overall: 8.37 x 2 x 9.62" / 212.60 x 50.80 x 244.35mm
With Antenna: 8.37 x 4.87 x 9.62" / 212.60 x 123.70 x 244.35mm
Without Antenna and Feet: 8.37 x 1.62 x 9.62" / 212.60 x 41.15 x 244.35mm
- Weight
- 4.28lbs / 1.94kg
|
Elite's brand-new universal disc player brings the spectacle of Ultra HD Blu-ray to your home entertainment, with four times the resolution of 1080p Full HD. Featuring three-block internal layout, Ultra Rigid Construction and Double-Layered Chassis for a robust build, 6-layered main circuit board, SDR/HDR preset mode and support for HDR10/Dolby Vision for quality picture, as well as premium audio DAC and Zero Signal Terminal for high-grade sound, the UDP-LX500 lets you enjoy the highest video resolution as well as your other digital disc collections.
Construction
• Three-Block Internal Layout (Power Supply, Drive/Digital Processing, Analog Audio)
• Ultra-Rigid Construction without Radiation Holes
• Double-Layered Chassis Reinforced with 3 mm Steel Plate for Rigidity and Low Center of Gravity
• 6-Layered Main Circuit Board for High S/N Ratio
• Rigid & Quiet UHD BD Drive
• Honeycomb Mechanism Drive Cover - Acoustic Damper Tray, Float-Mounting Structure
Video Features
• Ultra HD Blu-ray Playback
• SDR/HDR Preset Mode for Optimal Performance for the Display
• Video Adjust
• HDR10
• Dolby Vision (Low Latency Compatible)
• 36-bit Deep Color/"x.v.Color"
Audio Features
• Highly Precise D/A Conversion
• Direct Function for Pure Analog Audio Output
• Dual HDMI Output
• PQLS Jitter-less Sound Transmission via HDMI (with compatible AV Receiver)
Convenience
• Disc Information On-Screen Display
• BD-Live/BONUSVIEW
• Continued Viewing Playback
• 30 sec Skip Forward/10 sec Skip Back
• Auto Power Off
• Firmware Update (USB/Network)
• Self-Illuminating Remote Control
Ultra HD Blu-ray Playback
Certified by the UHD Alliance, the new Elite UDP-LX500 meets or exceeds strict performance specifications for resolution (4K - 4 times sharper than HD), high dynamic range (HDR - brilliant brights, deepest darks) and wide color spectrum (more lifelike colors). It also focuses on other video and audio attributes including immersive audio (multi-dimensional sound) among others. These performance advances guarantee the UDP-LX500 is able to fully replicate the richness of life's sights and sounds, enabling viewers to more accurately experience the content creator's vision.
Three-Block Internal Layout
The blocks for power supply, drive/digital processing and analog audio are separated into three to eliminate electrical and magnetic interference between the blocks.
Ultra-Rigid Construction without Radiation Holes
Even the holes for heat radiation are excluded to realize a flat form with optimal electric circuit design and minimum mechanical noise from the rotating system. The result is significantly low noise and even more rigid and stable chassis structure.
Double-Layered Chassis with Rigid Under Base for Rigidity and Low Center of Gravity
The 1.6 mm-thick chassis base is reinforced with a 3 mm-thick steel plate Rigid Under Base. This Double-Layered Chassis structure provides a low center-of-gravity and overall rigidity that prevents the transfer of external vibration to the inner chassis and offers a superior reading of the disc.
6-Layered Main Circuit Board for High S/N Ratio
A 6-layered IVH is used for the main circuit board to thoroughly eliminate digital noise. This optimizes the digital signal wiring and minimizes GND impedance and dramatically improves S/N ratio in audio/video signal processing. The 18 Gbps transmission through the latest HDMI standard becomes even more precise.
SDR/HDR Preset Mode for Optimal Performance for the Display
In addition to the video parameter "Reference" for reproducing the original master quality, you can select "LCD TV," "OLED TV," or "Projector" for the video quality best suited to your display. Additionally, there are SDR/HDR presets for each video parameter, that automatically switches between SDR preset and HDR preset according to the output signal.
Disc Information On-Screen Display
You can display the disc information on your screen by pressing and holding the remote control's DISPLAY button. In addition to the playing disc's details, you can easily check mastering information such as MaxFALL (Maximum Frame Average Light Level) and MaxCLL (Maximum Content Light Level) available on some HDR content, as well as HDMI output information .
PQLS Jitter-less Sound Transmission
With the precision quartz controller on a compatible AV receiver, Pioneer's PQLS (Precision Quartz Lock System) eliminates distortion caused by timing errors. It controls the amount of audio signals from the AV receiver to the UDP-LX500, giving the best possible digital-to-analog conversion. UDP-LX500 supports PQLS 2ch Audio, Multi-Surround and Bit-stream.
Zero Signal Terminal
The Zero Signal Terminal is a Pioneer-original feature dedicated to tuning audio and video quality without signal transmission. By connecting the Zero Signal Terminal with the audio/video input terminal of an AV receiver etc., the reference level (GND) of the audio/video signals is aligned between the two devices and the potential difference is suppressed, allowing a precise and high-quality signal transmission.
- Ultra HD Blu-ray Playback
- Three-Block Internal Layout (Power Supply, Drive/Digital Processing, Analog Audio)
- 6-Layered Main Circuit Board for High S/N Ratio
- PQLS Jitter-less Sound Transmission
- System
- NTSC
- Region
- Blu-ray: A
DVD: 1
- HDR Compatibility
- HDR10, Dolby Vision
- HD Upconversion
- No
- Video
- Ultra HD Blu-ray, 3D Blu-ray, BD-R, BD-R DL, BD-RE, BD-RE DL, BD-ROM, DVD+R, DVD+R DL, DVD+RW, DVD-Audio, DVD-R, DVD-R DL, DVD-ROM, DVD-RW, DVD-Video
- Audio
- CD-DA, CD-R, CD-ROM, CD-RW, SACD
- Output Ports
- 1x HDMI Type A
1x RCA (Analog Audio)
1x RCA (Digital Audio)
- Input Ports
- No
- USB Ports
- 2x USB Type-A
- Ethernet
- Yes
- Wi-Fi
- No
- Bluetooth
- No
- Control
- RS-232C
- Digital Media Slot
- No
- BD-Live
- Yes
- BONUSVIEW
- Yes
- Playback Media
- BD-ROM (UHDBD/3D BD/BD)/BD-R (DL)/BD-R LTH/BD-RE (DL)
DVD-ROM (DVD-Video/DVD-Audio)/DVD-R (DL)/DVD-RW/DVD+R (DL)/ DVD+RW
Audio CD (CD-DA/SACD)/CD-ROM/CD-R/CD-RW
USB Memory/HDD
- Terminals
- HDMI 2 Out (1 Main for Audio/Video, 1 Sub for Audio)
Digital Coaxial Out
Digital Optical Out
USB 2 In (1 Front, 1 Rear)
Ethernet
RS-232C
Analog Audio Out (Unbalanced)
Zero Signal Terminal (for Audio/Video Quality Tuning)
- AC Input Power
- 120 VAC, 60 Hz
- Power Consumption
- 28 W (Typical)
1.2 W (Idle)
0.4 W (Standby)
- ENERGY STAR Compliant
- No
- Dimensions (WxHxD)
- 17.13 x 4.63 x 13.25" (43.51 x 11.76 x 33.66cm)
- Weight
- 22.7 lbs (10.30kg)
|
AVENTAGE RX-A2A 7.2-channel AV Receiver with MusicCast
Take your entertainment to the next level. With professional quality video and immersive surround sound via Dolby Atmos, the RX-A2A will completely transform home cinema.
Breathtaking Sound
• Dolby AtmosDolby Atmos
• Dolby AtmosDolby Atmos with Height Virtualization
• DTS:XDTS:X
• High Slew Rate AmplifierHigh Amplifier
• Compressed Music Enhancer Compressed Enhancer
• MusicCast multi-room audioMusicCast audio
• Wi-Fi, AirPlay 2, 2 and Spotify Connect
• Streaming services include Spotify, Amazon Music, PandoraPandora, TIDAL, Deezer, Qobuz, Napster and SiriusXM, SiriusXM
• Zone 2
• Phono input
Movies and Games Like Never Before
• 4K60 Ultra HD with HDR, Dolby Vision, Hybrid-Log Gamma and BT.2020
• (7) HDMI inputs with HDCP 2.3 and eARC
• With future updates for HDMI 2.1, including: HDR 10+, 8K60B, 4K120AB and enhanced gaming features (ALLM, VRR, QMS, QFT)
Simple to Set Up, Simple To Use
• AV Setup Guide app
• MusicCast app
• Voice control with Alexa and Google Assistant devices; works with Siri via AirPlay 2
Designed For Your Space
• YPAO R.S.C. with multipoint
• Wireless rear surround capability
• Sleek, modern design
Dolby Atmos with Height Virtualization
Feel every dimension in Dolby Atmos. For those without in-ceiling or upward firing speakers in their systems, this height virtualization technology simulates the Atmos experience with forward-facing drivers.
DTS:X
DTS:X immersive audio formatting places sound where it would naturally occur in space, creating life-like, multi-dimensional audio. The included spatial remapping engine of DTS Neural:X offers improved immersion and heightened realism in all your favorite movies.
Anti-Resonance Technology Wedge
The Anti-Resonance Technology (A.R.T.) Wedge is a fifth foot in the center of the chassis unit base. It dampens vibrations from the power transformer, power transistors and heat sinks, as well as vibrations that might be caused by the sound from the speakers - providing dynamic sound and focused, accurate reproduction.
Cinema DSP 3D
This unique Yamaha proprietary sound field creation technology was created by combining measured sound field data with digital signal processing. By digitizing this vast trove of information and incorporating it into dedicated LSI devices, it effectively reproduces the spaces of concert halls and music clubs in your home. Immerse yourself in the astounding realism of your favorite movies and shows.
Movies and Games Like Never Before
8K60B, 4K120AB and 4K60
This receiver supports end-to-end 8K/4K resolutions and higher refresh rates, giving you a smoother and more realistic viewing experience.
HDR10+ and Dolby Vision
The latest enhancement for HDR provides deeper contrast and more realistic images that stay true to the creators' intent. Support for Dolby Vision, Hybid-Log Gamma and BT.2020 included.
Enhanced Media and Gaming Features (ALLM, VRR, QFT and QMS)
New enhanced gaming/media features offer seamless motion and transitions to enhance your performance.
Future Support for Multiple HDMI Inputs
Multiple HDMI inputs will equally support the latest HDMI technology to allow next-gen gaming consoles to be connected at the same time.
Simple to Set Up, Simple to Use
MusicCast App
Explore the power of multi-room audio, access your sources and streaming devices, and control your AV receiver, all through your phone or tablet.
Voice Control
Works with Alexa and Google Assistant, so your AV receiver is always at your command. Through AirPlay 2, you can stream your music via voice control with Siri from an Apple iOS device.
AV Setup Guide App
Offers expert guidance through installation, cable connections, and various other settings. Includes web setup for CI.
Designed For Your Space
Compatible with Wireless Surround Sound
Go wire-free with MusicCast Surround, letting you create a 5.1-channel surround sound system without the need to run wires to the back of the room. Connect wirelessly by connecting one MusicCast 50 or two MusicCast 20 wireless speakers to this AV receiver.
YPAO R.S.C. with Multipoint
YPAO (Yamaha Parametric Room Acoustic Optimizer) analyzes your room acoustics and measures speaker characteristics to optimize every channel of your home theater. R.S.C. (Reflected Sound Control) also optimizes sound parameters for maximum performance from CINEMA DSP, Dolby Atmos and DTS:X.
Dynamic and Compelling
Classic Yamaha craftsmanship meets cutting-edge design. Every piece has been carefully crafted to ensure this AV receiver looks and sounds perfect in your home.
- Breathtaking Sound
- Movies and Games Like Never Before
- Simple to Set Up, Simple To Use
- Designed For Your Space
- Dolby Atmos with Height Virtualization
- DTS:X
- Anti-Resonance Technology Wedge
- Cinema DSP 3D
- 8K60B, 4K120AB and 4K60
- HDR10+ and Dolby Vision
- Enhanced Media and Gaming Features (ALLM, VRR, QFT and QMS)
- Future Support for Multiple HDMI Inputs
- MusicCast App
- Voice Control
- AV Setup Guide App
- Compatible with Wireless Surround Sound
- YPAO R.S.C. with Multipoint
- Dynamic and Compelling
- Channel
- 7.2
- Rated Output Power
- 100 W (8 ohms, 0.06% THD) (20Hz-20kHz, 2-ch driven)
- High Slew Rate Amplifier
- Yes
- HDMI with eARC
- Yes
- HDR10, Dolby Vision
- Yes (via future update)
- Hybrid-Log Gamma and BT.2020, HDR10+
- Yes (via future update)
- MusicCast Surround
- Yes
- HDMI Input/Output (total)
- 7/1
- HDMI 4K60/4K120AB/8K60B support
- 3 / 1 (via future update)
- HDMI CEC
- Yes
- USB Input
- Yes
- Network Port
- Yes
- Wi-Fi
- Yes (2.4 / 5 GHz)
- AirPlay 2
- Yes
- Bluetooth
- Yes (SBC / AAC)
- Front Input
- USB
- Digital Audio Input/Output
- Optical: 1 / 0
Coaxial: 1 / 0
- IR In/Out
- 1/1
- Analog Audio Input/Output
- 4/0
- Zone 2
- Yes
- Phono Input
- Yes
- Preout
- 2.2-ch
- Headphone Output
- 1
- Standby Power Consumption (IR only)
- 0.1 W
- Auto Power Standby
- Yes
- ECO mode
- Yes
- Dimensions (W x H x D)
- 17.125 x 6.75 x 14.6" (43 x 17 x 37cm)
With antenna up: 17.125 x 9.62 x 14.6" (43 x 24.4 x 37cm)
- Weight
- 22.5 lbs (10kg)
|
Reviews
There are no reviews yet.
