| Content | LiveU LU300 with BirdDog BDP200 Live Production Bundle with IP Pipe PTZ Control
LiveU LU300 - Compact HEVC Field Unit for On-the-Go Live Streaming. The LU300 is a small-sized, cost-effective and reliable HEVC encoder, enabling broadcasters and other content creators to transmit high-quality video on-the-go.
BirdDog P200 - Combining BirdDog's custom NDI silicon chip, 30x optical zoom, and Sony backlit sensor and image module, the BirdDog Eyes P200, in black, is a full NDI 1080p60 PTZ camera designed for large indoor spaces. Thanks to the fast autofocus and zoom ensured by the true Sony image module, the P200 is highly suitable for catching all the fast action in places such as sporting events.
LiveU LU2000 - The LU2000 bonded video decoder is used to receive, decode and playout any HEVC/H.264 bonded video streams sent by LiveU’s range of field units. The LU2000 can also be used as a transmission node when sharing video over the LiveU Matrix video management and distribution platform.
LiveU IP Pipe - Enhance your remote production set-up and reduce costs by remotely controlling your IP-based gear. LiveU’s IP Pipe gives you remote control over a wide variety of network-based equipment.
| Bring UHD 4K quality video to your production with the white AW-UE150K UHD 4K 20x PTZ Camera from Panasonic. This pro PTZ camera outputs up to UHD 4K 60p over a variety of 4K connections including 12G-SDI, HDMI, optical fiber, and IP streaming. It features a large 1" type MOS sensor, a 20x optical zoom with a wide 75.1° angle-of-view, and PoE++ compatibility. With the v2.28 firmware upgrade, the AW-UE150W offers V-Log output, a UHD crop function in 720p, a preset on/off iris function, and more.
Camera features include an HDR mode with BT.2020 color gamut support, optical image stabilization (OIS), a fast 180° pan/tilt speed in high-speed mode, and an infrared Night Mode to capture wildlife or other low-light situations in monochrome HD video. A cropping function enables you to create a multicamera look by selecting up to three angles from a single 4K image.
The AW-UE150K camera supports embedded audio and audio input via a stereo mini-jack. Its redesigned web interface is compatible with PCs, Macs, tablets, and both Android and iOS smartphones. Additional features include an adjustable tally light, 1/4, 1/16, and 1/64 ND filters, and live streaming via RTMP. The AW-UE150W is upgradable to NDI/HX compatibility with a separately available license.
PoE++ Compatible
Power the camera using a separately available PoE++ (IEEE802.3bt) hub to minimize installation costs
Firmware Upgrade v2.28
Add V-Log output, a UHD crop function for 720/59.94p and 720/50p, a preset iris on/off function, and more by upgrading to firmware version 2.28
Features
-Large 1" type MOS sensor
-HDMI, SDI, and IP output up to UHD 4K
-20x optical, 32x iZoom in HD, 24x iZoom in UHD 4K
-Wide 75.1° horizontal angle of view (DRS)
-High Dynamic Range (HDR) mode with BT.2020 gamut support
-Optical Image Stabilization (IOS)
-Crop up to three shots from a single 4K image
-Large, adjustable tally light
-Adaptive Matrix function adjusts for strong LED blue light
1/4, 1/16, 1/64 ND filters
-Audio input and embedding
-Improved web UI for use with PC, tablet, or smartphone (iOS, Android)
-Maximum 180°/s pan/tilt in high-speed mode
-Monochrome Night Mode
-Digital Noise Reduction (DNR)
-Live streaming via RTMP
-Upgradable to NDI/HX with license
Video Output
- HDMI 2.0 standard 4:2:2/10bit
- HDCP is not supported.
- Viera Link is not supported.
- 12G-SDI OUT
- SMPTE 2082‑1 standard / 75 Ω (BNC x 1)
- 3G-SDI OUT
- SMPTE292 / 75 Ω (BNC x 1)
- Level-A/Level-B supported
- MONI OUT
- SMPTE292 / 75 Ω (BNC x 1)
- Optical Fiber SFP+ standard
- Single Fiber
- The signal sent is the same as 12G-SDI OUT.
- his unit does not support input by optical signals.
Zoom
- Optical zoom: 20x
- i.Zoom: UHD 24x, FHD 32x
- Digital zoom: 10x
Image Resolution: 3840×2160, 1920×1080, 1280×720, 640×360, 320×180
Power Requirements: 12 V DC (10.8 V to 13.2 V)
PoE++: IEEE802.3bt standard: DC 42 V to 57 V (Camera Input)
Current Consumption: 4.0 A (XLR IN connector), 1.2 A (PoE++ power supply)
Ambient Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Ambient Operating Humidity: 20 % to 90 % (no condensation)
Storage Temperature: –20 °C to 50 °C (–4 °F to 122 °F)
Mass: Approx. 4.2 kg (9.24 lb) (excluding mount bracket)
Dimensions (W x H x D): 213 mm x 267 mm x 219 mm (8-3/8 inches x 10-1/2 inches x 8-5/8 inches) (excluding protrusions, direct ceiling mount bracket)
Finish
- AW‑UE150WP/AW‑UE150WE: Pearl white
- AW‑UE150KP/AW‑UE150KE: Black
Controller Supported: AW-RP150GJ, AW-RP60GJ (Support planned for the future)*1, AW-RP50*1, AK-HRP1000GJ*1, AK-HRP1005GJ*1
Camera Unit
Imaging Sensors: 1-type 4K MOS×1
Lens
- Motorized Optical 20x zoom, F2.8 to F4.5
- [f=8.8 mm (11/32 inches) to 176.0 mm (6‑15/16 inches); 35 mm (1‑3/8 inches) equivalent: 24.5 mm (31/32 inches) to 490.0 mm (19‑9/32 inches)]
Conversion Lens: Not supported
Angle of View Range
- Horizontal angle of view: 75.1° (wide) to 4.0° (tele)
- Vertical angle of view: 46.7° (wide) to 2.3° (tele)
- Diagonal angle of view: 82.8° (wide) to 4.6° (tele)
Optical Filter: Through, 1/4, 1/16, 1/64, IR through (IR through is used as “Night mode”)
Focus: Switching between auto and manual
Focus Distance
- Entire zooming range: 1000 mm (3.3 ft)
- Wide end: 100 mm (0.33 ft)
Color Separation Optical System: 1MOS
Standard Sensitivity: F9, 2000 lx (When normal mode is selected)
Minimum Illumination: 2 lx (F2.8, 59.94p, 50IRE, 42 dB, without accumulation)
S/N: 60 dB or more
Horizontal Resolution: 1600 TV lines Typ (Center area)
Gain Selection
- Auto, 0 dB to 36 dB*2
- Super Gain function equipped : 37 dB to 42 dB
Frame Mix: 0 dB, 6 dB, 12 dB, 18 dB, 24 dB
Electronic Shutter Speed
- 59.94p/59.94i: 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- 29.97p: 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- 23.98p/24p: 1/24, 1/48, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- 50p/50i: 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- 25p: 1/25, 1/50, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
Synchro Scan
- 59.94p/59.94i: 60.00 Hz to 7200 Hz
- 29.97p: 30.00 Hz to 7200 Hz
- 23.98p/24p: 24.00 Hz to 7200 Hz
- 50p/50i: 50.00 Hz to 7200 Hz
- 25p: 25.00 Hz to 7200 Hz
Gamma: HD / FILMLIKE1 / FILMLIKE2 / FILMLIKE3/ FILM REC / VIDEO REC / HLG
White Balance
- ATW : 3200K, 5600K
- ATW Speed : Normal / Slow / Fast
- AWB : AWB-A / AWB-B
- VAR (selectable between 2000K and 15000K by designating a value)
Chroma Amount Variability: OFF, –99 % to 99 %
Scene File: Scene1, Scene2, Scene3, Scene4
Output Format
- 4K: 2160/59.94p, 2160/50p, 2160/29.97p*4, 2160/25p*4, 2160/24p*4, 2160/23.98p*4
- HD: 1080/59.94p, 1080/50p, 1080/29.97p*4, 1080/29.97PsF,1080/25p*4, 1080/25PsF, 1080/23.98p*5, 1080/24p*4, 1080/23.98p*4, 1080/23.98PsF, 1080/59.94i, 1080/50i,720/59.94p, 720/50p
Synchronization System: Internal / External synchronization (BBS / Tri-level sync)
INPUT
Input Connector
- DC 12 V IN, G/L IN (BNC)
- BBS (Black Burst Sync), tri-level sync supported
Input/Output Connector:
- LAN
- LAN connector for IP control (RJ‑45)
- RS-422
- CONTROL IN RS-422A (RJ‑45)
- MIC/LINE input
- ø 3.5 mm stereo mini jack Input impedance: High impedance
- During MIC input Supported mic: Stereo mic (plug-in power, on/off switching via menu) Supply voltage: 2.5 V ± 0.5 V Mic input sensitivity: Approx. –40 dBV ± 3 dBV (0 dB=1 V/Pa, 1 kHz)
- During LINE input Input level: Approx. –10 dBV ±3 dBV
Pan-tilt Head Unit
Camera/Pan-tilt Head Control:
- IP connecting cable
- LAN cable*6*7: (category 5e or above, straight cable / crossover cable) max. 100 m (328 ft)
- AW protocol connecting cable
- LAN cable*6 (category 5e or above, straight cable)
- max. 1000 m (3280 ft)
Installation Method: Stand-alone (Desktop) or suspended (Hanging)
Pan/tilt Operation Speed
- Minimum speed 0.08°/s
- Maximum speed 60°/s or higher
- Maximum speed is 180°/s in high-speed mode
Panning Range: ±175°
Tilting range: –30° to 210° 0
Quietness: NC35 or less
Supported operating systems and web browsers
- Windows
- Microsoft® Windows® 7, 10
- Windows® Internet Explorer® 11 (64‑bit/32‑bit)
- Microsoft Edge
- Google Chrome
- Mac
- Mac OS 10.13
- Mac OS 10.12
- Mac OS 10.11,
- Safari 11
- Google Chrome
- iPhone / iPad
- iOS 11.4.1
- Google Chrome
IP Streaming
Image Streaming Mode: JPEG (MJPEG), H.264, H.265
Image Transmission setting (JPEG):
- Frame Rate: Maximum 30 fps
- Image quality (Fine / Normal)
Image Transmission Setting (H.264)
- Image quality (Motion priority / Image quality priority) UHD 60 fps / 50 fps
- Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
- Transmission Priority: Constant bit rate, Frame rate, Best effort
- Frame Rate: [60Hz] 5fps/15fps/30fps/60fps (UHD: 30fps, 60fps)[50Hz] 5fps/12.5fps/25fps/50fps (UHD: 25fps, 50fps)
- Max Bit Rate
- HD:512kbps/768kbps/1024kbps/1536kbps/2048kbps/3072kbps/4096kbps/6144kbps/8192kbps/10240kbps/12288kbps/14336kbps/16384kbps/20480kbps/24576kbps/32768kbps/40960kbps/51200kbps/76800kbps
- UHD:12800kbps/25600kbps/51700kbps/76800kbps
Image Transmission Setting (H.265)
- Image Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
- Frame Rate: [60Hz] 30fps, [50Hz] 25fps
- Max Bit Rate: 8192kbps/12800kbps/25600kbps/51200kbps/76800kbps
- Audio Compression Type: AAC-LC, 48 kHz / 16 bit / 2ch
Supported Protocol
- IPv6 : TCP / IP, UDP / IP, HTTP, HTTPS, DNS, NTP, DHCPv6, RTP,MLD, ICMP, ARP, RTMP, RTMPS
- IPv4 : TCP / IP, UDP / IP, HTTP, HTTPS, RTSP, RTP / RTCP, DHCP, DNS, DDNS, NTP, UPnP, IGMP, ICMP, ARP, RTMP, RTMPS
Other Function
NDI support: NDI | HX
Tally LED display color: red / green | BDA300 PTZ camera utilizes BirdDog's custom NDI silicon chip and leverages an impressive Sony CMOS backlit sensor and full Sony Image Module.
Designed for serious production the image quality of A300 is best in class. Built on a true Sony Image module with Sony CMOS backlit sensor, A300 has super fast focus, incredibly sharp images, and amazingly fast zoom. A300 has frame rates up to 1080p60, 30x optical zoom, and outputs SDI, and NDI simultaneously
Full NDI. No compromises.
In the world of NDI there are two flavours, NDI and NDI|HX. NDI® is a variable bit rate, I-Frame codec that is reaches around 140Mbits at 1080p60 and is visually lossless. NDI|HX is a compressed, long-GOP, H.264 variant that reaches around 12Mbits at 1080p60. A300 only Encodes and Decodes Full YUV422 NDI
Sony Sensor. You deserve the best.
The best pictures come from the best silicon. A300 is teams up a world class Sony CMOS Backlit Sensor with the BirdDog custom NDI® chip to form a match made in silicon heaven. Your productions deserve the best.
Sony Image Module. Optics done right.
Lightning auto focus. Insanely fast zoom. Precision optics. The only way to achieve the best picture quality is with image module made by the world’s best. A300 uses a true Sony image module to give unparalleled performance, picture quality, and responsiveness.
All weather. Keep your NDI dry.
With an IP67 rating A300 is perfect for fixed installations in outdoor and indoor environments. The nitrogen filled housing ensures no fog, and the external housing has been treated for corrosion resistance against salt spray. With -40°C to +60°C operating temperature rating A300 has been designed to withstand the most extreme elements on earth
Nitrogen Filled Housing. Fog don’t live here.
Never worry about missing the shot. With A300’s nitrogen filled housing there is no chance of the lens fogging up
Category 4 Hurricane? Bring it.
Designed for all weather conditions, A300 boasts an incredible Wind Load Durability rating equal to 60m/s. As long as you have it secured properly A300 will just keep on keeping on
Frickin laser beam.Pew Pew.
Built in infra red laser with a range of up to 500 metres helps with focusing in
low light conditions.
Dual Output. NDI and SDI.
With NDI and SDI simultaneous outputs you can use the A300 is ready to go live with your full NDI® workflow, or if you are still in an old school SDI workflow you can control via RS422, RS485, and RS232 to future proof your investment by using baseband video now and move to NDI® when you are ready
30x Optical zoom. Over there is now over here.
The two punch 30x optical zoom and all weather abilities of makes A300 perfect for outdoor and indoor fixed installations for sports such as football, baseball, hockey, ski fields, basketball, soccer, and more.
You spin me right round baby. Right round.
360 degree continuous rotation, 255 preset positions, Zero Deviation Positioning technology, and a preset movement speed of 150 degrees per second mean you will never miss a shot again.
PTZ Keyboard. Take control.
Combine A300 with the BirdDog PTZ Keyboard and you have total control of all functions remotely. PTZ Keyboard is a full featured PTZ Keyboard that can control up to 255 PTZ cameras on a single network so can scale to even the most complex installations. PTZ Keyboard can control A300 over NDI® or by RS422 / RS232 when using in SDI mode.
PoE and Mounts. All options available.
A300 can be powered by PoE with an optional PoE Injector. Designed to hang upside down the choice of mounting options gives coverage for virtually any situation. Wall mount, Ceiling Mount, Corner Mount and Pole Mounting options all available
CAMERA
VIDEO OUTPUT
NDI/SDI
OPTICAL ZOOM
30x
IMAGE SENSOR
1 / 2.8 inch CMOS 2.13MP
LENS
4.3-129mm
DIGITAL ZOOM
12x
HORIZONTAL ANGLE OF VIEW
63.7° (W) – 2.3° (T)
APERTURE
F1.6 (W) – F4.7 (T)
MIN. ILLUMINATION
Color: 0.01 lux (F1.6, AGC on, 1/30s, High sensitive mode), 0.1 lux (F1.6, AGC on, 1/30s, Normal sensitive mode)
SHUTTER SPEED
1/1 – 1/10000s
FOCUS
Auto, Push, Manual
WHITE BALANCE
Auto, Indoor, Outdoor, Manual, OPW, ATW
EXPOSURE
Auto, Manual, Shutter/Iris Priority
BACKLIGHT COMPENSATION
YES
MECHANICAL
PAN MOVEMENT
Horizontal: ±360° continuous pan (Zoom Adaptive Speed Range: 0.01°〜80°/S )
TILT MOVEMENT
Vertical: +90° to -30° (Zoom Adaptive Speed Range: 0.1°〜90°/S)
PRESET POSITIONS
255 (Speed adjustable: Up to 150°/s)
ENVIRONMENTAL
Outdoor/Indoor, IP67, corrosion resistant treated housing, Wind load durability 60m/s, Nitrogen filled housing
OPERATING TEMPERATURE
-40 – +60 (°C)
OPERATING HUMIDITY
≤80%
ILLUMINATION
IR Laser, illumination up to 500m
VIDEO INTERFACE
VIDEO OUTPUT
NDI/SDI
VIDEO FORMATS
1080p 60, 59.94, 50, 29.97, 25
1080i 60, 59.94, 50
720p 60, 59.94, 50, 29.97, 25
AUDIO I/O
3.5mm Audio In (Stereo)
3.5mm Audio Out (Stereo)
CONTROL INTERFACE
IP PTZ CONTROL
NDI Control (auto configuring)
SERIAL PTZ CONTROL
RS422/RS485 Connector
SERIAL CONTROL PROTOCOL
VISCA / Pelco D
POWER & DIMENSIONS
POWER INPUT
AC 24v, PoE 80W Ready (BirdDog PoE 80W Injector needed, optional)
POWER CONSUMPTION
Min. 24W, Max. 80w (-40°C, IR Laser ON)
DIMENSIONS
180x180x423mm
WEIGHT
10.2kg
NETWORK
VIDEO COMPRESSION
Full NDI – i-frame high quality low latency NDI for production
NETWORK PROTOCOL
NDI – Discovery, configuration and control
WEB CONTROL INTERFACE
Full control via Web/Mobile UI including Scene presets | Instantly connect with multiple contacts around the world.
NewTek TalkShow VS 4000 is the only professional, multi-channel calling production system for both SDI and IP workflows, designed exclusively for conducting multiple live, production-ready Skype video calls with any combination or sequence of contacts anywhere in the world— simultaneously—in distraction-free, broadcast-quality HD.
Reach 300 million monthly Skype users with:
- 4 concurrent Skype video channels
- 4-in, 4-out HD-SDI connections
- Integrated NDI™ technology supporting input and output over IP
- Included NDI™ Webserver
- Tally notification on all call channels
- The most complete audio and video capabilities
More live guests. More compelling conversations.
Facilitate captivating real-time group conversations, panel discussions, and live interview after live interview with remote guests that enhance the quality and credibility of your program.
Independent Control Interfaces
Easily set up a multi-operator production workflow, with separate interfaces for call and production management. Skype TX Control software can be operated from the TalkShow VS 4000 system or installed on another machine as a standalone call control center, allowing the producer to manage calls and talent, while a production operator handles video and audio.
Group or Queue Callers
Connect with any combination of guests from around the world simultaneously or in sequence, for compelling live conversation, expert analysis, real-time commentary, and in-depth discussion.
IP Networking
Receive video calls over IP anywhere on your network. Built-in NewTek NDI technology allows routing of Skype video calls to any compatible NDI receiving device (including TriCaster® and 3Play™) while enabling selection of any NDI video source for return to caller over the network.
Advanced Audio
Deliver conversations that sound more professional. Independently adjust incoming and outgoing audio signals for the highest-quality sound, with the only video calling system that offers built-in gain control, graphic equalizer, compressor/limiter, and noise gate settings.
Pristine Live Video
Ensure your guests look as good as they sound, with enhanced real-time image processing and fully configurable correction tools, including proc amp controls, auto color setting, and white balance—and clean, deinterlaced return video to caller.
Real-Time Call Monitoring
Conduct every call with complete confidence, by utilizing high-quality, full-motion video previews, accurate on-screen audio VU metering, and selectable multi-view display layouts with configurable monitor overlays.
| Hardware Video Input |
4 x HD-SDI with embedded audio |
| Hardware Video Output |
4 x HD-SDI with embedded audio |
| Hardware Audio Input |
4 x embedded SDI audio
2 x Balanced XLR (Line) |
| Hardware Audio Output |
4 x embedded SDI audio
2 x Balanced XLR (Line) |
| IP Networking |
Integrated NewTek Network Device Interface (NDI) technology enabling transmission of A/V input and output signals over IP between TalkShow and other supported systems, including TriCaster, 3Play and a range of third-party solutions |
| Dante Audio Networking |
Integrated Dante audio support, enabling TalkShow to interface with other audio devices utilizing the Dante networking protocol from Audinate |
| Call Recording |
Supports full-bandwidth recording of call video and audio (optionally including return audio on separate channels) to external USB 3.0 or SAN storage |
| Video Configuration |
- Fully configurable color correction settings for each incoming Skype video signal, including white balance, proc amp controls and auto color
- Freely selectable video source for return to each Skype caller
|
| Audio Configuration |
- Fully configurable settings for each incoming Skype audio signal, including gain control, seven-band equalizer, compressor/limiter, and noise gate
- Freely selectable audio source and mix-minus channel control for return to each Skype caller
|
| Talk Back |
Supports direct, off-air communication between operator and remote callers individually or as a group via headset (optionally configurable for control via external GPI trigger) |
| Call Management |
- Supports multi-channel Skype TX call management locally or over IP via Skype TX controller application
- Local production control supporting per-channel configuration of call video and audio, and Talk Back communication via TalkShow user interface
- Direct mouse and keyboard USB interface required
|
| Local Monitoring |
- DVI and HDMI ports for connecting external monitors
- Stereo 1/4” phone jack for local audio monitoring
- Full-motion input and output video previews within user interface, including optional picture-in-picture overlay of return video for each call monitor
- Configurable multi-view workspace, including selectable layouts and optional overlays including title safe, 4:3 safe, center cross and VU meters
- Audio VU metering
|
| Output Video Formats |
Configurable call video output resolution and frame rate, with support for NTSC and PAL formats
- 1080i – 25, 29.97, 30
- 1080p – 23.98, 24
- 720p – 50, 59.94, 60
- 576i (16:9 or 4:3) – 25
- 480i (16:9 or 4:3) – 29.97
|
| Return Video Formats |
Configurable return video input resolution and frame rate, with support for NTSC and PAL formats (available selections vary depending on output video format selected)
- 1080i – 29.97, 25
- 1080p – 30, 30 PsF, 24, 24 (Telecine), 25, 25 PsF
- 720p – 30, 25, 24
- 576i (16:9 or 4:3) – 25
- 480i (16:9 or 4:3) - 29.97
|
| Watermark |
Optionally supports Skype logo watermark on output |
| Tally |
Supports hardware tally via HD15 GPI connector or network tally via NewTek NDI |
| GPI |
HD15 GPI connector |
| Reference |
- Genlock input supporting SD (Bi-level) or HD (Tri-level) reference signals
- +4dBU audio reference level
|
| Signal Monitoring |
Integrated Waveform and Vectorscope, full field rate with digital calibration, color preview and support for ITU-R Rec. 601 and 709 |
| Software |
Microsoft Windows 10 OS, Skype TX 4 software, Skype TX controller application, and TalkShow control software |
| CPU |
4th Generation i7 Quad-Core |
| Graphics |
Intel HD4600 GPU |
| Memory |
8Gb |
| Storage |
120Gb internal SSD |
| Processing |
Video: 4:4:4:4, 32-bit Floating Point
Audio: 4 channels, 96 kHz, 32-bit Floating Point |
| Standards |
HD-SDI video conforms to SMPTE 292M
SD-SDI video conforms to SMPTE 259M |
| Network |
Dual gigabit Ethernet NIC supporting Skype TX call transmission, NDI transmission to and from supported systems, Dante audio networking, and local network traffic |
| Fail-Safe |
- Multi-tiered fail-safe system
- Automatic failover to audio transmission with caller snapshot when bandwidth falls below operator-defined preset value
- Comprehensive system restore operation
|
| System Physical |
1RU Rack Mount with 180W power supply (110-220V external; 12V internal)
- 19.0 x 1.75 x 16.75 in (48.3 x 4.5 x 42.5 cm) with rack ears attached
- 15 lbs (6.8 kg)
|
| Bring UHD 4K quality video to your production with the white AW-UE150W UHD 4K 20x PTZ Camera from Panasonic. This pro PTZ camera outputs up to UHD 4K 60p over a variety of 4K connections including 12G-SDI, HDMI, optical fiber, and IP streaming. It features a large 1" type MOS sensor, a 20x optical zoom with a wide 75.1° angle-of-view, and PoE++ compatibility. With the v2.28 firmware upgrade, the AW-UE150W offers V-Log output, a UHD crop function in 720p, a preset on/off iris function, and more.
Camera features include an HDR mode with BT.2020 color gamut support, optical image stabilization (OIS), a fast 180° pan/tilt speed in high-speed mode, and an infrared Night Mode to capture wildlife or other low-light situations in monochrome HD video. A cropping function enables you to create a multicamera look by selecting up to three angles from a single 4K image.
The AW-UE150W camera supports embedded audio and audio input via a stereo mini-jack. Its redesigned web interface is compatible with PCs, Macs, tablets, and both Android and iOS smartphones. Additional features include an adjustable tally light, 1/4, 1/16, and 1/64 ND filters, and live streaming via RTMP. The AW-UE150W is upgradable to NDI/HX compatibility with a separately available license.
PoE++ Compatible
Power the camera using a separately available PoE++ (IEEE802.3bt) hub to minimize installation costs
Firmware Upgrade v2.28
Add V-Log output, a UHD crop function for 720/59.94p and 720/50p, a preset iris on/off function, and more by upgrading to firmware version 2.28
Features
-Large 1" type MOS sensor
-HDMI, SDI, and IP output up to UHD 4K
-20x optical, 32x iZoom in HD, 24x iZoom in UHD 4K
-Wide 75.1° horizontal angle of view (DRS)
-High Dynamic Range (HDR) mode with BT.2020 gamut support
-Optical Image Stabilization (IOS)
-Crop up to three shots from a single 4K image
-Large, adjustable tally light
-Adaptive Matrix function adjusts for strong LED blue light
1/4, 1/16, 1/64 ND filters
-Audio input and embedding
-Improved web UI for use with PC, tablet, or smartphone (iOS, Android)
-Maximum 180°/s pan/tilt in high-speed mode
-Monochrome Night Mode
-Digital Noise Reduction (DNR)
-Live streaming via RTMP
-Upgradable to NDI/HX with license
Video Output
- HDMI 2.0 standard 4:2:2/10bit
- HDCP is not supported.
- Viera Link is not supported.
- 12G-SDI OUT
- SMPTE 2082‑1 standard / 75 Ω (BNC x 1)
- 3G-SDI OUT
- SMPTE292 / 75 Ω (BNC x 1)
- Level-A/Level-B supported
- MONI OUT
- SMPTE292 / 75 Ω (BNC x 1)
- Optical Fiber SFP+ standard
- Single Fiber
- The signal sent is the same as 12G-SDI OUT.
- his unit does not support input by optical signals.
Zoom
- Optical zoom: 20x
- i.Zoom: UHD 24x, FHD 32x
- Digital zoom: 10x
Image Resolution: 3840×2160, 1920×1080, 1280×720, 640×360, 320×180
Power Requirements: 12 V DC (10.8 V to 13.2 V)
PoE++: IEEE802.3bt standard: DC 42 V to 57 V (Camera Input)
Current Consumption: 4.0 A (XLR IN connector), 1.2 A (PoE++ power supply)
Ambient Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Ambient Operating Humidity: 20 % to 90 % (no condensation)
Storage Temperature: –20 °C to 50 °C (–4 °F to 122 °F)
Mass: Approx. 4.2 kg (9.24 lb) (excluding mount bracket)
Dimensions (W x H x D): 213 mm x 267 mm x 219 mm (8-3/8 inches x 10-1/2 inches x 8-5/8 inches) (excluding protrusions, direct ceiling mount bracket)
Finish
- AW‑UE150WP/AW‑UE150WE: Pearl white
- AW‑UE150KP/AW‑UE150KE: Black
Controller Supported: AW-RP150GJ, AW-RP60GJ (Support planned for the future)*1, AW-RP50*1, AK-HRP1000GJ*1, AK-HRP1005GJ*1
Camera Unit
Imaging Sensors: 1-type 4K MOS×1
Lens
- Motorized Optical 20x zoom, F2.8 to F4.5
- [f=8.8 mm (11/32 inches) to 176.0 mm (6‑15/16 inches); 35 mm (1‑3/8 inches) equivalent: 24.5 mm (31/32 inches) to 490.0 mm (19‑9/32 inches)]
Conversion Lens: Not supported
Angle of View Range
- Horizontal angle of view: 75.1° (wide) to 4.0° (tele)
- Vertical angle of view: 46.7° (wide) to 2.3° (tele)
- Diagonal angle of view: 82.8° (wide) to 4.6° (tele)
Optical Filter: Through, 1/4, 1/16, 1/64, IR through (IR through is used as “Night mode”)
Focus: Switching between auto and manual
Focus Distance
- Entire zooming range: 1000 mm (3.3 ft)
- Wide end: 100 mm (0.33 ft)
Color Separation Optical System: 1MOS
Standard Sensitivity: F9, 2000 lx (When normal mode is selected)
Minimum Illumination: 2 lx (F2.8, 59.94p, 50IRE, 42 dB, without accumulation)
S/N: 60 dB or more
Horizontal Resolution: 1600 TV lines Typ (Center area)
Gain Selection
- Auto, 0 dB to 36 dB*2
- Super Gain function equipped : 37 dB to 42 dB
Frame Mix: 0 dB, 6 dB, 12 dB, 18 dB, 24 dB
Electronic Shutter Speed
- 59.94p/59.94i: 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- 29.97p: 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- 23.98p/24p: 1/24, 1/48, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- 50p/50i: 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- 25p: 1/25, 1/50, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
Synchro Scan
- 59.94p/59.94i: 60.00 Hz to 7200 Hz
- 29.97p: 30.00 Hz to 7200 Hz
- 23.98p/24p: 24.00 Hz to 7200 Hz
- 50p/50i: 50.00 Hz to 7200 Hz
- 25p: 25.00 Hz to 7200 Hz
Gamma: HD / FILMLIKE1 / FILMLIKE2 / FILMLIKE3/ FILM REC / VIDEO REC / HLG
White Balance
- ATW : 3200K, 5600K
- ATW Speed : Normal / Slow / Fast
- AWB : AWB-A / AWB-B
- VAR (selectable between 2000K and 15000K by designating a value)
Chroma Amount Variability: OFF, –99 % to 99 %
Scene File: Scene1, Scene2, Scene3, Scene4
Output Format
- 4K: 2160/59.94p, 2160/50p, 2160/29.97p*4, 2160/25p*4, 2160/24p*4, 2160/23.98p*4
- HD: 1080/59.94p, 1080/50p, 1080/29.97p*4, 1080/29.97PsF,1080/25p*4, 1080/25PsF, 1080/23.98p*5, 1080/24p*4, 1080/23.98p*4, 1080/23.98PsF, 1080/59.94i, 1080/50i,720/59.94p, 720/50p
Synchronization System: Internal / External synchronization (BBS / Tri-level sync)
INPUT
Input Connector
- DC 12 V IN, G/L IN (BNC)
- BBS (Black Burst Sync), tri-level sync supported
Input/Output Connector:
- LAN
- LAN connector for IP control (RJ‑45)
- RS-422
- CONTROL IN RS-422A (RJ‑45)
- MIC/LINE input
- ø 3.5 mm stereo mini jack Input impedance: High impedance
- During MIC input Supported mic: Stereo mic (plug-in power, on/off switching via menu) Supply voltage: 2.5 V ± 0.5 V Mic input sensitivity: Approx. –40 dBV ± 3 dBV (0 dB=1 V/Pa, 1 kHz)
- During LINE input Input level: Approx. –10 dBV ±3 dBV
Pan-tilt Head Unit
Camera/Pan-tilt Head Control:
- IP connecting cable
- LAN cable*6*7: (category 5e or above, straight cable / crossover cable) max. 100 m (328 ft)
- AW protocol connecting cable
- LAN cable*6 (category 5e or above, straight cable)
- max. 1000 m (3280 ft)
Installation Method: Stand-alone (Desktop) or suspended (Hanging)
Pan/tilt Operation Speed
- Minimum speed 0.08°/s
- Maximum speed 60°/s or higher
- Maximum speed is 180°/s in high-speed mode
Panning Range: ±175°
Tilting range: –30° to 210° 0
Quietness: NC35 or less
Supported operating systems and web browsers
- Windows
- Microsoft® Windows® 7, 10
- Windows® Internet Explorer® 11 (64‑bit/32‑bit)
- Microsoft Edge
- Google Chrome
- Mac
- Mac OS 10.13
- Mac OS 10.12
- Mac OS 10.11,
- Safari 11
- Google Chrome
- iPhone / iPad
- iOS 11.4.1
- Google Chrome
IP Streaming
Image Streaming Mode: JPEG (MJPEG), H.264, H.265
Image Transmission setting (JPEG):
- Frame Rate: Maximum 30 fps
- Image quality (Fine / Normal)
Image Transmission Setting (H.264)
- Image quality (Motion priority / Image quality priority) UHD 60 fps / 50 fps
- Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
- Transmission Priority: Constant bit rate, Frame rate, Best effort
- Frame Rate: [60Hz] 5fps/15fps/30fps/60fps (UHD: 30fps, 60fps)[50Hz] 5fps/12.5fps/25fps/50fps (UHD: 25fps, 50fps)
- Max Bit Rate
- HD:512kbps/768kbps/1024kbps/1536kbps/2048kbps/3072kbps/4096kbps/6144kbps/8192kbps/10240kbps/12288kbps/14336kbps/16384kbps/20480kbps/24576kbps/32768kbps/40960kbps/51200kbps/76800kbps
- UHD:12800kbps/25600kbps/51700kbps/76800kbps
Image Transmission Setting (H.265)
- Image Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
- Frame Rate: [60Hz] 30fps, [50Hz] 25fps
- Max Bit Rate: 8192kbps/12800kbps/25600kbps/51200kbps/76800kbps
- Audio Compression Type: AAC-LC, 48 kHz / 16 bit / 2ch
Supported Protocol
- IPv6 : TCP / IP, UDP / IP, HTTP, HTTPS, DNS, NTP, DHCPv6, RTP,MLD, ICMP, ARP, RTMP, RTMPS
- IPv4 : TCP / IP, UDP / IP, HTTP, HTTPS, RTSP, RTP / RTCP, DHCP, DNS, DDNS, NTP, UPnP, IGMP, ICMP, ARP, RTMP, RTMPS
Other Function
NDI support: NDI | HX
Tally LED display color: red / green | BirdDog Eyes P200 Camera: Designed for serious production the image quality of P200 is best in class. Built on a true Sony Image module with Sony CMOS backlit sensor, P200 has super fast focus, incredibly sharp images, and amazingly fast zoom. P200 has frame rates up to 1080p60, 30x optical zoom, and outputs SDI, HDMI, and NDI simultaneously.
BirdDog PTZ Keyboard: BirdDog PTZ Keyboard is a full featured PTZ Keyboard that supports NDI®, NDI|HX, Visca over IP, RS422, and RS232. By harnessing BirdDog’s next generation NDI® and IP technology, it’s never been easier to discover, connect, and control your PTZ cameras. Featuring superior ergonomics, premium buttons and joystick, all in a beautiful form factor this is the PTZ controller you have been waiting for. Universal control. Mix and Match protocols. |
Reviews
There are no reviews yet.
