| Content | Brand New, in sealed original box, never used, in perfect condition!
Tascam product info:
Built-in DSP 4 line outputs Dante converter to respond to various needs of contractor market and professional audio scene.
The ML-4D/OUT-E is a compact converter that converts Dante input signals into 4-channel line output signals. With half the size of a standard 1U rack, the ML-4D/OUT-E is suitable for different Dante systems as an exquisite analog output unit. The built-in DSP mixer enables small scale systems to fully perform with a variety of input/output models the TASCAM Dante Compact Processor Series offers. ML-4D/OUT-E supports up to 96kHz/24bit and uses Euroblock connectors for analog line output.
4 line output
4 Dante input/output
Supports PoE (Power over Ethernet)
Up to 24bit/96kHz
Includes a variety of DSP functions for optimal use in different scenes/environments (Output effects, 4 in/4 out matrix mixer)
Supports Dante daisy chain; this allows two Dante Compact Processor models to be connected without a network switch
Compatible with Dante Domain Manager and Dante AES67 Mode
Flexible scene preset function allows to work in different area situations (Up to 50 presets)
Timer event function allows to automatically switch scenes at a specified time (planned to be compatible on a future version update)
2 types of user control software available for Windows/Mac/iOS/Android devices:
For integrators: input/output routing selection, DSP/design/scene settings of the complete system, etc.
For end-users: simple app design for only the necessary functions such as area volume settings, etc.
Remote control via GPI and Dante
Half-rack mountable size
Equipped with indicators that show LAN/Dante connection status and sample rate
Equipped with signal indicators that monitor line output signals
Configurable reference level (via remote control only) | SPL MixDream Analogue Summing Unit
- Analogue outboard summing mixer
- Active Class A/60-volt stages
- 16 inserts for mixing external effects
- Individual and overall bypass relays
- Reduced of A/D conversions
- Efficient resampling individual tracks
- Latency-free monitoring
- Stereo expansion control for additional transparency
- Analogue peak limiter for gain optimisation
- Lundahl output transformers and inserts
- Adjustable insert levels, output levels and peak limiters
- Multiple units linkable for larger mixes
| UF8 is SSL’s latest studio controller, designed for today’s DAW-based production workflows and ultrafast turn-around times. An expandable 8-channel advanced DAW controller, UF8 connects engineers, producers and artists directly to the creative process, offering absolute command of their workflow and significantly accelerating the speed of audio production and content creation.
UF8 is the culmination of SSL’s 40+ year legacy of mastering production workflows and studio ergonomics built into generations of classic SSL consoles. This depth of understanding of studio production, combined with decades of engineering excellence, delivers a premium finish tactile USB controller that distills SSL workflow and quality. | RÉSUMÉ DES FONCTIONNALITÉS
Images de 24, 32, 40 et 48 canaux
Options de canal mono / stéréo A, B, C, D
Mélanges principaux LR et M
8 groupes audio avec panoramique et routage vers LR et M
10 auxiliaires dont un envoi stéréo dédié avec commandes de niveau et de panoramique
2 canaux stéréo multifonctions chacun avec entrées micro et ligne stéréo
2 doubles stéréos supplémentaires fournissent 4 retours stéréo additionnés ou indépendants
Matrice 12 × 4 complète
Double fonctionnalité appropriée pour FoH, mixage de moniteur ou les deux
Enregistrement capable avec des sorties directes de canal
M peut être utilisé pour le mixage centre / sous, la somme mono LR ou le coin d'ingénierie
Entrées externes matricielles avec trims de niveau et capacité d'entrée commune
Les entrées micro du canal stéréo peuvent se croiser dans la matrice pour une alimentation d'ambiance
EQ réactif 4 bandes, 2 balayages
Filtres passe-haut de canal 100Hz
Alimentation fantôme individuelle et commutation de polarité
Compteur intégré avec 11 VU-mètres à bobine mobile éclairés par LED
Canal LED grand angle et compteurs principaux
Compteurs de contrôle stéréo dédiés
Commutation auxiliaire par canal pré / post fader pour une flexibilité totale
Commutateurs pré / post-EQ du panneau avant pour les préférences de l'utilisateur
Coupe le son de tous les faders masters
Faders à double rail de qualité supérieure de 100 mm
Talkback assignable à toutes les sorties, comprend un mode de verrouillage de commutateur de conversation
Oscillateur 1 kHz / générateur de bruit rose avec sortie externe
Surveillance 2 pistes et relecture sur LR
3 prises casque / écouteurs et sorties moniteur locales
Sorties XLR symétrisées électroniquement avec capacité d'entraînement + 26 dBu
Gamme de préamplis 74 dB avec capacité d'entrée +34 dBu pour micro ou ligne
Conception d'ampli micro à très faible bruit
Combiner intégré pour une alimentation de secours redondante
Assemblage de cartes de circuits individuelles avec des pots écroués
Option de liaison d'entrée / sortie de console Sys-Link V2
Douilles de lampe XLR 4 broches - Lampe LED Allen & Heath disponible.
Options de canal mono / stéréo:
A = tous les canaux mono
B = 4 stéréos à droite des masters
C = 4 stéréos à l'extrême droite
D = 8 stéréos à l'extrême droite | Working inside the box? Sweetwater would like to recommend a summing mixer that will seriously up your game: the Rupert Neve Designs 5059 Satellite Shelford Edition. If you record and mix entirely within your DAW, you’re hampered by the inability to leverage the sonic advantages of high-quality analog outboard gear. Enter the 5059 Satellite. The 5059 gives you 16 channels — each with individual level and pan, plus insert and bus-2 send buttons. You get two stereo buses with RND’s proprietary Silk Texture controls, giving you effortless integration with outboard equipment, total control for two separate stem mixes, and the facility to dial in harmonic enhancement in two distinct flavors.
It’s a Neve
In serious audio circles, Rupert Neve needs no introduction. Large-format Neve consoles from the 1970s are considered by many to be the pinnacle of analog mixer design. Boasting the same design heritage and sonic perfectionism that went into the boards used to record countless hit records, the 5059 Satellite Summing Mixer graces your tracks with legendary Rupert Neve warmth, punch, and presence. With 16 channels of Rupert Neve designed Class A alchemy and flexible tonal and routing options, the Rupert Neve Designs 5059 Satellite Summing Mixer will take your DAW-based studio’s sound to a whole new level.
Dial in the Silk
The Rupert Neve Designs’ 5059 Satellite Summing Mixer’s continuously variable Texture controls with Silk and Silk+ modes let you fine-tune the harmonic ratio and tonality of each of 5059’s stereo buses. The Silk mode adds sparkle to your tracks by introducing alluringly airy transformer saturation in the high frequencies. Silk+ mode accentuates saturation in the low frequencies, adding density and thickness to the source — particularly desirable when you’ve got a dry, lackluster mix. Distinctly different sounding from equalization, Texture saturates the output transformers, adding sweet, musical even-order harmonics to your source material for authoritative, radio-ready mixes that blast right out of the speakers.
Flexibility: it’s a beautiful thing
The dual stereo outputs of the Rupert Neve Designs 5059 Satellite Summing Mixer are perfect for creating stem mixes, which you can enhance using the 5059’s Silk/Texture controls, then process through bus compressors or other devices via the inserts, finally feeding into the inputs of another mixer or your interface. You can send any input to stereo bus 1 or 2, and create two very different-sounding mixes from the same 16 channels. These are just some examples of the amazing flexibility you’ll enjoy when integrating the 5059 into your recording rig. Smartly attired in classic Shelford livery, the Rupert Neve Designs 5059 Satellite Summing Mixer is housed in a rugged, fan-cooled 2U steel chassis for dependable, no-compromise professional performance year after year, in the studio or on the road.
The legend continues
Rupert Neve’s 80-series consoles had a huge, punchy, and authoritative sound that defined the sound of ’70s rock. From London to New York to Los Angeles and beyond, top studios were installing Neve boards as fast as they could. By 1977, with the introduction of the NECAM automation system, 80-series boards were the main component of the success formula for any recording studio with world-class aspirations. Mr. Neve’s current company, Rupert Neve Designs, continues to advance the state of the art with cutting-edge products that sound incredible and intelligently address the challenges of the digital age. With your Rupert Neve Designs 5059 Satellite Shelford Edition from Sweetwater, the legend continues.
Rupert Neve Designs 5059 Satellite Summing Mixer Shelford Edition Features:
- Classic Neve: Class A, all transformer-balanced, and awesome-sounding
- Zero crossover distortion and unmatched purity
- Custom transformers provide galvanic isolation and serve up "larger than life" sound
- Sets a standard for rackmountable summing mixers
- 16 inputs/channels (with level controls, pans, and inserts); 2 stereo buses
- Send any input to stereo bus 1 or 2, each with variable Silk/Silk+ Texture
- Dual Stereo Outputs let you split the input channels into 2 stems for further processing and mixing
- Stereo buss 1 and 2 each has its own XLR outs
- DB-25 line input, insert send/return connectors
- Rugged 2U fan-cooled chassis, clad in classic Shelford livery
| The A-Designs Mix Factory takes a fresh approach to analog summing, delivering analog warmth with the depth and imaging needed to make your mixes truly stand out. Mix Factory inputs 16 channels and sums to balanced stereo outputs. All channels are fitted with gain controls, pan pots, and mutes. Two 8-channel groups are provided, each has an insert with mute button, and there is a master insert for all 16 channels. Mix Factory lets you switch between "clean," which bypasses the transformers, to "tonal," which introduces the harmonic enhancement of custom Cinemag output transformers. The Mix Factory is linkable, letting you expand to 64 or more channels. Take your studio to the next level with the A-Designs Mix Factory.
Benefits of the hybrid studio
Producer/engineer Tony Shepperd came up with the idea for Mix Factory, and it was brought to life by noted circuit design wizard Paul Wolff. Mr. Shepperd had been one of the modern engineers who subscribed to the "all-in-the-box" school of digital music production. At some point, however, he came to believe that digital and analog could very well coexist in the contemporary studio in a synergistic union that delivered additional "best-of-both-worlds" sonic benefits. This hybrid approach worked exceptionally well for Tony, taking his mixes to a new level. So much so that other engineers took notice and started asking him for tips. Today, most high-end recording facilities (including Sweetwater Studios) are hybridized in one sense or another. A-Designs' Mix Factory is a smart and cost-effective way to realize the many advantages of this approach.
A-Designs Mix Factory Features:
- 2RU 16-channel analog summing mixer
- 2 x 8-channel Groups
- All channels fitted with gain controls, pan pots, and mutes
- Switchable Cinemag output transformers
- Linkable, for easy studio expansion
- External power supply (included) switches between 120V and 230V
|
